Racerstar Racing Edition 2205 BR2205S PRO 2600KV 2-4S Brushless Motor For X210 X220 250 FPV Racing Frame
Description:
Brand: Racerstar
Item name: BR2205S PRO 2600KV Brushless Motor
RPM/V: 2600KV
Height: 33mm
Width: 27.9mm
Shaft diameter: M5
Motor mount hole size: M3
Weight: 28 grams
Voltage: 2-4S
Battery: 2-4S lipo battery
Internal resistance: â¦
Usage: X210 X220 250 280 FPV Racing Frame
Tested with 14.8V voltage 5045 propellers:
Load current: 32.5A
Pull: 950g
Power: 452W
Efficiency: 2.1 (g/W)
CW screw thread motor comes with red cap
CCW screw thread motor comes with black cap
Features:
Stainless steel motor shaft
Copper wire stable up to 200°.
N50 magnet, stronger magnetism.
Thicker shaft, higher intensity.
Internal cooling fins design.
Ventilative side holes on the motor pedestal to help to heat dissipation.
Package included:
1 x BR2205S PRO 2600KV Brushless Motor
