Specification:
Brand Name: Racerstar
Model: TaiChi
Item Name: F4 OSD 2-6S Flight Controller AIO BEC & 40A BL_32 4in1 ESC Stack
Mounting Hole: 20x20mm
Stack Weight: 23g
Application: for 120mm-250mm Frame Kit
F4 OSD 2-6S Flight Controller Board (Top Level)
CPU: STM32F405R6T6
MPU: MPU6000-SPI
Input Voltage: 2-6S Lipo
Built-in Betaflight OSD to adjust PID
BEC Output: 5V/2A
Size: 32.2x32.2mm
Installing Hole: 20X20mm, M2
Weight: 4.8g
40A BLHeli_32 DShot1200 4in1 ESC ( Bottom Level)
40A BLHeli_32 DShot1200 4in1 ESC ( Bottom Level)
CPU: STM32F051
Input Voltage: 2-6S Lipo battery
Constant Current: 40A
Burst Current: 45A (10s)
BEC Ouput: NO
Firmware: BLHELI_32
Size: 38.7x38x6.8mm
Installing Hole: 20x20mm, M2
Weight: 14.2g
- Support Oneshot42, Oneshot125, Multishot, DShot150,300,600 and DShot1200
Package Included:
1x Racerstar TaiChi F4 Flight Control
1x Racerstar TaiChi 40A BL32 4in1 ESC
1x XT60H power connector
1x XT30U Connector(18AWG)
2x 100mm 14 AWG power cable
8x M2*6 Damping rubber column
8x M2 damping O-ring
1x 35V 1000uf capacitance
1x 25V 220UF capacitance
4x M2x22mm screw
1x 8pin cable
