Description:
Resolution:600TVL
Image device: 1/4” CMOS
Frequency: 5.8GHz 6 bands 48 channels
Output power: 25mw/200mw Switchable
Frequency band: 5362~5945MHz
Singal system: PAL / NTSC (Switchable)
Sensor: PAL:720X540/NTSC:640X480
Field of view: H:120°/V:100°
Input power: 7v~16.8v(2s-4s lipo)
Output Characteristic:
25mw 6V 150MA±40MA
200mw 6V 350MA±50MA
Input Impedance 75Ω
Peak Deviation: 1.2MHz
Frequency control:PLL
Frequency Stability: ±100KHz (Typ.)
Frequency precision:±200KHz (Typ.)
Weight: 5.4g
Transmission frequency group
A:Ch1:5740MHz Ch2:5760MHz Ch3:5780MHz Ch4:5800MHz
Ch5:5820MHz Ch6:5840MHz Ch7:5860MHz Ch8:5880MHz
B:Ch1:5705MHz Ch2:5685MHz Ch3:5665MHz Ch4:5645MHz
Ch5:5885MHz Ch6:5905MHz Ch7:5925MHz Ch8:5945MHz
C:Ch1:5865MHz Ch2:5845MHz Ch3:5825MHz Ch4:5805MHz
Ch5:5785MHz Ch6:5765MHz Ch7:5745MHz Ch8:5725MHz
D:Ch1:5658MHz Ch2:5695MHz Ch3:5732MHz Ch4:5769MHz
Ch5:5806MHz Ch6:5843MHz Ch7:5880MHz Ch8:5917MHz
E:Ch1:5733MHz Ch2:5752MHz Ch3:5771MHz Ch4:5790MHz
Ch5:5809MHz Ch6:5828MHz Ch7:5847MHz Ch8:5866MHz
F:Ch1:5362MHz Ch2:5399MHz Ch3:5436MHz Ch4:5473MHz
Ch5:5510MHz Ch6:5547MHz Ch7:5584MHz Ch8:5621MHz
Features:
1. Ultra small volume and lightweight.
2. 2s-4s powered FPV transmitter camera system.
3. 5.8G 48CH Raceband.
4. PAL / NTSC Switchable.
5. The lens can be flipped vertically.
6. 600TVL 120 degree ultra wide angle camera.
7. Optimized circuit structure,reliable filter capacitor,strong anti-interference ability.
Package included:
1 x FPV Camera
1 x 5cm IPEX Antenna
