Detrum DVT58 200mW 800m 5.8G 48CH FPV VTX Racing Transmitter For Racer Drone - 17.99 €

Detrum DVT58 200mW 800m 5.8G 48CH FPV VTX Racing Transmitter For Racer Drone
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

Detrum DVT58 5.8G 200mW 48CH FPV VTX Racing Transmitter For Racer Drone



Introduction

This is a 48 channels 5.8G 200mW wireless transmitter, installed on the aircraft, for FPV use. The transmission range is as far as 800m in open area without any block.

Features

The output power of DVT58 is 200mW. The transmission distance is as far as 800m
48 channels adjustable, the channel number can be displayed on the LED digital display
Single button and single LED digital display, super small size, lightweight, portable for the aircraft
Integrated wires and plugs, easy to install
Multiple receivers can be linked at the same time, make it possible that everyone can hold a display to watch the video separately

Specifications

Working Frequency: 5.8GHz ISM
Output Power: 200mW Channel: 48 CH
Input Voltage: DC 7V~17V
Supply Current: 260mA/12V
Video Input Impedance: 75Ω
Video Band Width: 8MHz
Video Format: NTSC/PAL
Working Temperature: -40~85℃
Dimension (L×W×H): 32×21×9mm
Weight: 10g (without antenna)


Channel and frequency table

CH

FR

CH

CH1

CH2

CH3

CH4

CH5

CH6

CH7

CH8

FR

FR1

5865MHz

5845MHz

5825MHz

5805MHz

5785MHz

5765MHz

5745MHz

5725MHz

FR2

5733MHz

5752MHz

5771MHz

5790MHz

5809MHz

5828MHz

5847MHz

5866MHz

FR3

5705MHz

5685MHz

5665MHz

5645MHz

5885MHz

5905MHz

5925MHz

5945MHz

FR4

5740MHz

5760MHz

5780MHz

5800MHz

5820MHz

5840MHz

5860MHz

5880MHz

FR5

5658MHz

5695MHz

5732MHz

5769MHz

5806MHz

5843MHz

5882MHz

5917MHz

FR6

5362MHz

5399MHz

5436MHz

5473MHz

5510MHz

5547MHz

5584MHz

5621MHz

Packing List

1 x DVT58 200mW
1 x 4-pin connector to DuPout connector and JST connector Cable

Note:
The antenna is not included, you need to purchase separately.
DVT58 200mW must be connected with antenna when working. It is more stable and has better performance when using with 5.8G Omni-directional Mushroom Antenna.
