Description:
Brand Name: Foxeer
Item Name: Razer Mini
Color: Black, Red (optional)
Scale: 4:3 / 16:9(optional)
Lens: 1.8mm, 2.1mm (optional)
Sensor Type: 1/3 CMOS
TV System: PAL / NTSC Switchable
Resolution: 1200TVL
FOV: 4:3 FOV-H 125°, FOV-D 155° / 16:9 FOV-H 125°, FOV-D 145°
Shutter Speed: PAL: 1/25~1/10000 sec; NTSC: 1/30~1/10000 sec
Video Out: CVBS
Min. Illumination: 0.01Lux
White Balance: Auto
DNR: 3DNR
WDR: 90db
Day / Night Shift: EXT / Auto / Color / B&W
Power Requirement: DC 4.5V~25V
Language: English / Chinese / Pyccknn / Espanol / Francais / Polski / Italiano / Portugues / Japanese / Korean / Eaahnika
Working Temperature: -10â ~ +50â RH90% MAX
Working Humidity: 20~80%
Storage Temperature: -20â ~ +70â
Storage Humidity: 20~95%
Dimension: 21.8x21.8mm (without bracket)
Weight: 12g
Features:
- 1200TVL definition with advanced natural image.
- HD 5MP 2.1mm M12 Lens.
- 4:3/16:9 optional, PAL/NTSC switchable.
- Supports 4.5~25V input voltage.
Package Included:
1x Foxeer Razer Mini Cam
1x Bracket (21 to 28)
1x Servo Cable
1x 2pin OSD Cable
1x OSD Board
1x Manual
1x Screws
