FrSky R9M 2019 900MHz Long Range Transmitter Module and R9 SX OTA ACCESS 6/16CH Long Range Enhanced Receiver Combo with Mounted Super 8 and T antenna
Specifications:
Brand Name: FrSky
Item Name: R9M Module and R9 SX Receiver
Weight: 100g
Version: FCC/LBT Version (Optional)
FrSky 900MHz R9M 2019 Long Range Module System
OVERVIEW:
FrSky R9 and R9M radio control system is the first FrSky long-range system that works in the frequency of 900MHz. The R9M module offers 4 switchable RF power outputs so you can choose the appropriate power for different flight situations. Compared to another FrSky 2.4GHz long range receiver like the L9R, the R9 receiver has a longer operating range up to 10KM and above. Moreover, the R9 is also a redundancy receiver that can connect to another receiver to ensure the security of your aircraft.
Description:
Compatibility: R9 series
Vin Voltage Range: 6.5V-13V
External Power Supply: 6.5V~13V
Telemetry Interface: Smart Port
Upgrade Interface: Smart Port
Modulations: PXX or CPPM (auto-detected)
Features:
- 900MHz/868MHz working mode
- Long-range, low latency and high precision RC system
- 4 Optional RF power (Non-EU Version)
- Telemetry modeï¼25mWï¼/non-telemetry modeï¼200mW / 500mWï¼ (EU Version)
- RF Power (Flex): 10mW/ 100mW/ 500mW/ 1W (telemetry supported for all levels)
- Smart Port enabled and support telemetry data transmission
Description:
Frequency: 868MHz / 915MHz
Dimension: 36*17*7mm / 47.5*20.5*11mm (including case and pins)
Weight: 8.8g / 13g (including case and pins)
Numbers of Channel: 6 PWM / 16 SBUS (CH16 outputs RSSI)
Operating Voltage: DC 3.5V~12.6V
Operating Current: 100mA@5V
Compatibility: R9M Lite/ R9M Lite Pro / R9M 2019 with ACCESS firmware
Features:
- ACCESS protocol and supports OTA functions
- 900MHz/868MHz long-range with low latency
- Enhanced and durable design
- 6 standard servo connectors (default PWM channel)
- Switchable CH5/CH6 into S.Port/SBUS Output channels
- Support S.Port / F.Port (Configurable in OpenTX / FrOS menu)
- Signal redundancy function
- External battery detection
- Detachable Ipex1 connector antenna
Package Included:
1 x R9M 2019 Module with mounted Super 8 antenna
1 x R9 SX OTA with mounted Ipex4 T antenna
