HolyBroKakuteF7HDVisdesignedtoworkwiththeDJIFPVVTx module.TheGHportavailableonthe
boardmakesitmuchmoreconvenientforyoutoconnectHolyBroKakuteF7HDVtotheDJIFPVVTx,for
bothsignalandpower.
New BLHELI32 ESC with F3 MCU, give more smooth control and faster
responding speed. Supports up to 55A burst and 40A continued.
Specifications:
| KakuteF7HDV Flight Controller | MCU:STM32F745 32-bitprocessor IMU:PMU6000 Barometer:BMP280 USBVCPDriver(allUARTsusablesimultaneously;USBdoesnottakeupaUART) 6hardwareUARTS(UART1,2,3,4,6,7) AllUARTSsupporthardwareinversion.SBUS,SmartPort,andotherinvertedprotocolsworkon anyUARTwithout“uninverthack”. Supportsserialreceivers(SBUS,iBus,Spektrum,Crossfire)only.PPMandPWMreceiversarenot supported. TFcardforBlackboxlogging Dimensions: 35x35mm MountingHoles: Standard30.5mmsquaretocenterofholes Weight: 8g |
| Tekko32 F3 HDV 40A ESC | 32bit ESC with BLHELI32 firmware Supports 3-6S lipo input PWM input, TLM supported Voltage output (VBAT) NO BEC Supports oneshot / Multishot / Dshot PWM Mounting holes 30.5x30.5mm Supports damped light F3 MCU, runs double faster than F051 Extra Cap needed for high current or 6s usage Dimensions: 44x37x6mm Weight: 11.6g |
Features:
• SupportsBetaflight,Butterflight,andCleanflight.
• High-performance/low-noiseIMU.MPU6000with6-axisgyroandaccelerometer.
• Readyforautonomousflight:IntegratedBMP280 barometerandSCL/SDAforusewithexternal
GPS/magnetometerunits.
• Dedicatedbootloaderbuttonforeasyfirmwareflashing.
• Low-profiledesignfitsintoevenverycompactframes.
• Inputvoltage7vto42v.Powertheboarddirectlyfromtheflightpack,upto6S(on“B+”pad
only).
• Automaticvoltagemonitoring.NoneedtorunaseparatevBatwireforvoltagemonitoring;the
KAKUTEF7HDV monitorsvoltagedirectlyfromthepowersupply.
• Filteredvoltageoutputforclean,noise-freevideo.2On-boardregulatorsoutput5V and8V.5V
output upto1.5A topowerperipheralssuchasreceiver,FPVcamera,orLEDstrip. 8Voutputup
to2AtoDJIFPVVTx.
• SupportsBLHelipass-throughforeasyESCupgradeandconfiguration.
Package Included:
1 x Kakute F7 HDV Flight Controller
1 x Tekko32 F3 HDV 40A Brushless ESC
Package Included:
1 x Kakute F7 HDV Flight Controller
1 x Tekko32 F3 HDV 40A Brushless ESC
1 x Electrolytic capacito: 1000uF 35v
1 x 8pin to 8pin 1mm pitch 65mm cable
1 x 8pin to 8pin 1mm pitch 25mm cable
