Description:
Model: IDC-WIFI720
Interface Type: CIS/SD/UART/2S/AudioCodec
Storage format: .H264
Supply voltage: 3.8V-5.5V (±10%)
Module current: 230mA (measured at 5V)
Video CIS input: 1280x720p@25, data bit width 10bit, frame valid, line valid signal polarity configurable
Video output: 1280x720p@25
Support: Sensor OV9732
Antenna type: external antenna
Product size: 37.75mm (length) x 18.85mm (width) x 5.6mm (height)
Protocol/Standard: IEEE802.11b, IEEE 802.11g, IEEE802.n (1T1RModes)
Frequency range: 2.400~2.4835GHz
Channel: 1~11 (USA, Canada), 1~13 (Europe), 1~14 (Japan)
Modulation mode: 802.11b: DSSS (CCK, DQPSK, DBPSK)
802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM)
Transmit power: 802.11b/g/n: 17±1dbm
Working temperature: -10 ° C -60 ° C
Working humidity: 10%-90% RH without condensation;
Features:
* 802.11n-compliant, up to 150Mbps video and control signals for wireless transmission;
* Gamma correction, color correction, automatic dead pixel correction, adaptive 3D/2D denoising, m0tion detection & privacy masking;
* Support defogging;
* Use a high compression rate video compression chip to control the data rate to enhance the transmission distance;
* Highly integrated design, smaller size and lower power consumption;
* Low power operation supporting deep sleep and standby modes;
* Support client video synchronization transmission;
* The air transmission distance is 100 meters;
* Support remote storage mode;
* Support single video recording;
Package Included:
1x IDC-WIFI720P Wifi Mini FPV Video Transmitter Integrated With 720P 150° Wide Angle FPV Camera
