IFlight Ion Drive ID2207 2207 2500KV 1660KV 3-4S Brushless Motor for RC Drone FPV Racing - 17.00 €

IFlight Ion Drive ID2207 2207 2500KV 1660KV 3-4S Brushless Motor for RC Drone FPV Racing
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


IFlight Ion Drive ID2207 2207 2500KV 1660KV 3-4S Brushless Motor for RC Drone FPV Racing

Specification:
Brand Name: IFlight
Model: Ion Drive ID2207
Item Name: 2207 2500KV 1660KV 3-4S Motor
KV: 2500KV / 1660KV ( Optional)
Version: CW Screw Thread
Configuration: 12N14P
Shaft Diameter: 4mm
Internal Resistance: 46mΩ
Motor Dimensions (Dia.*Len): Φ27.7×17.3mm
ldle current@10v(A): 1.4A
No.of Cells(Lipo): 3-4S
Max Continuous Power 180s: 424W
Max Continuous Current 180s: 24.6A
Weight : 37.2g (with wire)
AWG: 18#
Cable length: 150mm

Features:
-7075 milled aluminium Bell and Base
-NMB Japan 4mm bearings
-High temperature magnets and windings
-N52H Arc Magnets
-Hex bolt shaft set screw
-Dynamically balanced

Test Table:

KV Voltage Propeller Throttle Current (A) Power (W) Pull (g) RPM Efficiency
1660KV 16.8V Gemfan 5152 100 18.3 307 1043 21780 2.63
1660KV 16.8V iFlight T5061 100 19.5 332 1185 20910 2.76
1660KV 16.8V Geprc 5040 100 14.1 241 945 22300 2.46
1660KV 16.8V HQ 7045 100 27.8 433 1386 18900 2.42
2500KV 16.8V Gemfan 5152 100 38.9 593 1486 26280 2.23
2500KV 16.8V Gemfan 5051 100 43.2 665 1432 26880 2.18
2500KV 16.8V Geprc 5040 100 34.2 528 1359 27780 2.33
2500KV 16.8V iFlight T5061 100 47.5 678 1662 25800 2.07
2500KV 16.8V DAL 5045 100 36.7 560 1399 27180 2.15

Package Included:
1x iFlight ID2207 Motor
1x bag of Screws
