PRODUCT DESCRIPTION
SucceX 2-6S Mini F4 Tower is specially designed for Micro FPV racers, which includes advanced SucceX mini F4 Flight Controller with SucceX 35A 4 in 1 ESC, that can handle up to 6s batteries and push your FPV racer to sky highly. The FC and ESC neatly stack together with pinned interconnects that make your build easy to assemble and cleaner looking. This tightly pre-built stack will fit any frame that has 20 x 20mm mounting holes.
The SucceX Mini F4 Tower is the fastest way go from starting a new micro build to FPV Flight!
The new released SucceX Mini F4 flight control has been optimized overall. The main soldering port has been upgraded to terminal plugs, which is convenient for pilots to assemble and disassemble. The F405 MUC equipped with the MPU6000 gyroscope is optimized for better flight performance. Programmable RGB LED interface has been built-in for external LED to set LED color, function, and status. The built-in OSD chip helps to monitor the status of the flight data any time.
The latest developed BLHeli-32-bit 35A 4-in-1 mini ESC is highly integrated, greatly reduced from the standard size, features excellent performance, supports 6S, the target is iFlight-BL32-4IN1.Supporting Dshot, Multishot, Oneshot, etc. The soldering pad is semi-extended, save more room but solid.
Features:
STM32 F405 MCU FC w/OSD, integrated MPU6000 accelerometer and gyro;
Plug-in connection, pin header design, easy to install and disassemble;
BLHeli-32-bit 35A 4-IN 1 ESC
Compact size 26*26*xxmm
Super-lightweight xxg(including screws,aluminum column & nuts)
SucceX mini F4 Flight Controller Specs:
MCU: 100MHz STM32F405
IMU: MPU6000 gyro/accelerometer (SPI)
Integrated LC Filter
Input Voltage: 2-6S Lipo
OSD: BetaFlight OSD w/ AT7456E chip
BEC Output: 5V@3A
Size: 26x26mm board, 20mm mounting holes (M2)
VCP, UART
WS2812 Led Strip: Yes
Beeper: For active 5V buzzer
Target: omnibus
SucceX Mini 35A 2-6S 4 in 1 ESC Specs
MCU:STM32F051
Current Sensor: no
Input:2-6s lipo
Installing Hole: 20x20mm, M2
Target
Constant:35Amps
Burst:45Amps
Dimensions:31*31mm(including the power pads)
Mounting Holes:20*20mm
Supports Dshot1200, Proshot,Oneshot,Multishot
Package included (Pre-built as a stack):
1 x SucceX mini F4 Flight Controller
1 x SucceX Mini 35A 2-6S 4 in 1 ESC
1 x Cable Set
