Long Wires New DYS XM30A mini ESC Electronic Speed Controller For High KV Power

Description:

Input voltage: 3-6s Lipo

BEC: NO

Size(mm): 38L*16.5W*6H

Type: BLHeli Bootloader & Firmware

Weight: 9.26g

Built-in capacitor

Specially designed for high KV power racing motors.

Features:

-XM series ESC is the upgraded version of the SN series with advanced processor, a basic frequency up to 50MHz, and faster overall processing capacity to better support high KV motors

-Designed for quick multi-rotor throttle response

Twisted pair cable is used to deliver throttle signal, reducing signal crosstalk while further stabilizing copper wire transmission

-New miniaturization and ultra-low resistance MOSFET, powerful flow resistance, and professional MOS Drive chips improve efficiency

-Newly designed PCB board improves impact resistance.

Sub-miniaturization design reduces weight while still providing a high performance filtering capacitor

-Refresh rate of throttle signal up to 500Hz, compatible with all modern flight controllers, including the Naze32 Rev6 and SP Racing F3

-Ultra-high speed Oneshot125 with 3000Hz refresh rate provides quick, smooth throttle response

-Fully programmable via USB port, with two-way and 3D modes for high speed racing and acrobatics.

Package Included:

1 x ESC
