Micro Scisky MX NAZE 32 X Flight Control Board 1S/2S Support Baseflight Cleanflight For Multirotor Quadcopter
MX NAZE 32 is designed on the basis of the original NAZE 32, MX NAZE 32 supports both Baseflight firmware and Cleanflight firmware, for using on different models, MX NANO 32 gets different types.
Item NO.: MX NAZE 32 X
Item Name: Flight Control Board
Model: 1S, 2S, 1S with barometer (Optional)
Dimension: 32.0*19.6*7.2mm (not including case)
Working voltage: 3.3~4.5V or 5~10V
Receivers supports: PPM, DSM2, DSMX, SBUS
2)Option for integrated with DSM2 compatible 7CH receiver;
3)Type X is with DCDC boost (output 5V/500mA),it can supply power for outside device;
4)Independent ports for IIC, GPS, PPM/DSM/SBUS receivers;
5)Supports both Baseflight firmware and Cleanflight firmware;
6)Can work with 1S and 2S lipo battery
7)Type X is with 1.5mm pitch port.
Size for MX NAZE 32 flight control board (unit: mm):
Ports for MX NAZE 32 flight control board:
When the pads inside the blue square box on the following picture are used, the working voltage will be 3.3V~4.5V (1S lipo is recommended); When the pads inside the red square box are used, the working voltage will be 5.0V~10.0V (2S LIPO is recommended or power supplied through an outside BEC).
LED lights meaning:
Red LED—power; blue LED—flying mode; green LED—unlock;
How to connect a receiver:
There is a RX-S port (1.25mm 3P) which is special for connecting an outside receiver, it supports signal input of PPM, DSM2/DSMX, SBUS, it also support 3.3V or VIN output (Note 1), in order to connect an outside receiver, short connecting pads on RX-S and changing type of receiver on GUI at the same time is the way.
1) When output is VIN, and VIN>5.5V, please make sure if the outside receiver supports 5.5V or more, or the outside receiver may be burnt;
2) As it gets an integrated receiver, as soon as the integrated receiver is set to output banned(RF circuit of the integrated receiver won’t work at the moment), the outside receiver can work without problem.
1 x MX NAZE 32 X Flight Control Board
