Racerstar 35A ESC Brushless Waterproof 1/14 1/16 1/18 RC Car Part - 15.99 €

Racerstar 35A ESC Brushless Waterproof 1/14 1/16 1/18 RC Car Part
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


Racerstar 35A ESC Brushless Waterproof 1/14 1/16 1/18 RC Car Part















Description:
Brand: Racerstar
Item: Brushless 35A ESC
Waterproof Level: Splash-proof

ESC Features:
- Specially desighed for RC car with excellent start-up, acceleration and linearity feartures
- Compatible with sensorless brushless motor
- The strong resistant current capability, excellent heat dissipation
- Multiple protection features: low voltage cut-off protection for lithium or nickel battery / over-heat protection / throtttle signal loss protection / motor blocked protection
- Easily programmed and compatible with pocket-sized program card

ESC Specifications:
Model 25A 35A 45A 60A 80A 120A Cont. Current/
Burst Current 25A/100A 35A/120A 45A/180A 60A/320A 80A/480A 120A/600A Motor Type Sensorless Brushless Motor Suitable Car 1/18, 1/16 1/18, 1/16, 1/14 1/10 1/10 1/8 1/8 Suitable Brushless Motor ≥12T ≥12T ≥9T ≥9T ≥5.5T ≥3.5T Resistance 0.004ohm 0.003ohm 0.0014ohm 0.0007ohm 0.0005ohm 0.00035ohm Battery 2 cells Lipo
4-6 cells NiMH 2-3 cells Lipo
4-9 cells NiMH 2-3 cells Lipo
4-9 cells NiMH 2-3 cells Lipo
4-9 cells NiMH 2-4 cells Lipo
4-12 cells NiMH 2-6 cells Lipo
4-18 cells NiMH BEC Output 5V/2A
(analog mode) 5V/2A
(analog mode) 5.8V/3A
(switch mode) 5.8V/3A
(switch mode) 6.1V/3A
(switch mode) 6.1V/3A
(switch mode) Dimension 25*30*14.5mm 25*30*18.5mm 32.5*34*24mm 32.5*34*24mm 41*51*36mm 41*51*36mm
Instructions:
1. Connect BEC wires with the receiver
2. Connect motor wires with ESC
3. Turn on the transmitter
4. Connect battery pack with ESC then switch on the ESC
5. When the connection of motor and battery is finished, the motor emits "Beep-Beep" tone
6. When the throttle stick is the neutral position, the motor re-emits "Beep-Beep" tone
7. The ESC is workable

For ESC program card, please click


Package Included:
1 X ESC
1 X Manual
