Specifications:
Aircraft
Wheelbase: 215mm
Weight: 375g ( excluding battery )
Transmitter: DEVO 7 7-channel
Flight controller: FCS - F215
Brushless motor: WK-WS-28-017 2500KV
Brushless ESC: Furious 215 ESC
Propeller: 5040 5 inch
Battery: 14.8V 1300mAh 60C 4S LiPo
Flight time: 8 - 9 minutes
Working temperature: -10 to 40 Deg.C
Camera
Lens: 2.5mm
Image sensor: 1/3 inch Super HAD II CCD
Resolution: 600TVL
Integrated microphone: yes
WDR: D-WDR
DNR: 2DNR
Day / night: Color / Auto / Black and White
Power supply: 5 - 17V
Video Transmitter
Model: TX5838 ( FCC )
Frequency: 5.8GHz
Channels: 8
Transmission distance: 1.5km
Output power: 200mW or less
DEVO 7 Transmitter
Frequency: 2.4GHz DSSS
Output power: 100mW or less
Current consumption: 230mA ( 100mW ) or less
Power supply: 8 x 1.5V AA battery ( not included )
Specification
General |
Brand: Walkera
Type: Frame Kit Version: RTF |
|---|---|
Motor |
Model: WK-WS-28-017
Motor Type: Brushless Motor KV: 2500 CW / CCW: CCW,CW |
Flight Controller |
Flight Controller Type: F3 |
Remote Controller Specifications |
Channel: 7-Channels
Remote Control: 2.4GHz Wireless Radio Control Mode: Mode 2 (Left Hand Throttle) FPV Distance: 1.5km Transmitter Power: 8 x 1.5V AA battery(not included) Model Power: Rechargeable Battery |
Camera |
Video Resolution: 600TVL
Sensor: CCD |
Electronic Speed Controller |
Functions: Oneshot125,Oneshot42 |
Battery |
Battery (mAh): 1300mAh
Battery Voltage: 4S Battery Coulomb: 60C Flying Time: 8~9mins Charging Time (h): 2 hours |
Dimension and Weight |
Product weight: 0.3750 kg
Package weight: 1.9000 kg Product size (L x W x H): 16.80 x 20.90 x 7.15 cm / 6.61 x 8.23 x 2.81 inches Package size (L x W x H): 30.00 x 30.00 x 30.00 cm / 11.81 x 11.81 x 11.81 inches |
Package Contents |
Package Contents: 1 x Drone ( with Battery ), 1 x Transmitter, 1 x Charger, 4 x Spare Propeller, 1 x English Manual, 1 x Accessory |
