Specification
| General | |
|---|---|
| Type | Transmitter |
| Model | Skyzone T600 |
| Frequency | 5.8G |
| Channel | 32CH |
| Connector | SMA |
| Operating Temperature | -10-85 Degrees |
| Power Supply | Output Impedance: 50 Ohm Output Power: 26-27dBm Operating Voltage: 7-24V Supply Current: 220mA |
| Video | Video Format: NTSC/PAL Video Brand Width: 0-8MHz Video Input Impedance: 75 Ohm |
| Audio | Audio Carrier Frequency: 6.5MHz Audio Input Level: 0.5-2.0 Vp-p Audio Input Impedance: 10K Ohm |
| Frequency | FR1(A) 5865M,5845M,5825M,5805M,5785M,5765M,5745M,5725M FR2(R) 5658M,5695M,5732M,5769M,5806M,5843M,5880M,5917M FR3(E) 5705M,5685M,5665M,5645M,5885M,5905M,5925M,5945M FR4(F) 5740M,5760M,5780M,5800M,5820M,5840M,5860M,5880M |
| Dimension/Weight | Weight: 25g Dimension: 35 x 45 x 13mm |
| Package Contents | |
| 1 x transmitter | |
| 1 x antenna | |
| 1 x cable | |
