Highlights
- That`s right 2000mW video transmitting POWER
- Best FPV gear, powerful 5.8GHz transmitter
- Thunderbolt with a precision machined housing that plays double duty to keep the transmitter cool with integrated heat sink and internal fan
- A clear LCD for channel selection and SMA-RP style antenna connection
- A ready to use 5 pin cable for power, video and audio connections, and clear instructions with a Duck style Omni antenna
- For best range and video link stability, we recommend Boscam 5.8GHz Cloud Spirit circular-polarized Antenna Set (SMA-RP)
Specification
| General | |
|---|---|
| Type | Transmitter |
| Model | Boscam FPV TS5833 |
| Transmitting Frequency | 5645-5945MHz, 8 Channels |
| Transmitting Power | 2000mW (33dB +-1dB) of certified output power |
| Cooling System | Whole body heat sink and cooling fan |
| Channel Switching | Channel button and channel display |
| Antenna | RP-SMA female 50 ohm connector |
| Power On Working | Plug and Play |
| Input Voltage | 7-24V DC |
| Battery | 2-6 cells |
| Size/Weight | Size: 62mm*42mm*20mm (L*W*H) Weight: 37g |
| Channel Number | Channel 1 ----5705 MHz Channel 2 ----5685 MHz Channel 3----5665 MHz Channel 4----5645 MHz Channel 5----5885 MHz Channel 6----5905 MHz Channel 7----5925 MHz Channel 8----5945 MHz |
| Package Contents | |
| 1 x 5.8G 2000mW 8 Channels Wireless AV Transmitter(with antenna) | |
| 1 x 5pin multi function cable | |
| 1 x Power line | |
| 1 x Transfer cable | |
