Specification:
Brand Name: Holybro
Item Name: F7 Flight Controller & 5.8G 40CH VTX Stack
Stack Height: 17mm
Mounting Hole: 20x20mm
Holybro Katute F7 Mini V3 Flight Controller ( Manual) | MCU: STM32F722RET6 32-bit processor,216MHz, 256Kbytes Flash IMU: MPU6000 (SPI) Barometer: BMP280 USB VCP Driver (all UARTs usable simultaneously; USB does not take up a UART) 5 hardware UARTS (UART1,2,3,4,6,7) Supports serial receivers (SBUS, iBus, Spektrum, Crossfire) only. PPM and PWM receivers are not supported. Onbord 16Mbytes for Blackbox logging 5V Power Out: 1.0A max 3.3V Power Out: 0.2A max Dimensions: 30x30mm Mounting Holes: Standard 20mm square to center of holes Weight: 4g - has Connection Port for DJI FPV& Caddx Vista VTX ( More details, pls read manual) |
Atlatl HV Micro VTX ( Manual) | Output Power: 0.5 mW (pit mode), 25mW, 200mW, 500mW, 800mW Audio: 6.5 MHz Mono Protocolï¼smart audio2.0 Antenna Connector: MMCX Mounting Holes: Standard 20mm square to center of holes (M3) Weight: 3.6g |
FPV Transmitter Features:
- Compatible with all major FPV receivers from vendors such as Fatshark, ImmersionRC, etc.
- Supports the standard 40-channel set: band A, B, E, Fatshark, and Raceband.
- SmartAudio input allows remote control by the flight controller. Change channel, transmit power,
and more from Betaflight OSD, flight controller USB port, Taranis Lua Script, and more.
- All parameters are controllable via push-button on the side of the unit, for cases where SmartAudio is not used.
- MMCX connector is durable and easy to use. Rated for 100âs of mating cycles. Easy and quick antenna changes. No more ripped-off UFL connectors.
- LED indicators for channel, band, and power. Allows easy check of vTX parameters simply by glancing at the quad.
- Variable transmit power from 25 mW to 800 mW. Use 25 mW for a race and then easily switch to 800 mW for freestyle.
- 0.5 mW True Pit Mode allows you to power up safely without the risk of knocking other pilots out of the air.
- Built in microphone, so you can listen to your motors while you fly, no matter how far away you fly.
- Standard 26mm form factor allows you to mount the Atlatl directly on your flight controller stack.
Package Included:
1x Kakute F7 mini V3 Flight Controller
1x Atlatl HV Micro VTX
1x JST SH 8pin 150mm Cable
1x JST SH 8pin 150mm Cable
1x 80mm SMA--MMCX Cable
1x 150mm 4pin JST GH wire
1x 60mm Antenna
1x bag of Screws
