Specification: ( Manual)
Brand Name: HGLRC
Model: F760 Stack
Item Name: F7 Flight Controller & 60A 4In1 ESC Flytower
Stack Weight: 32.7g
Application: compatible with 100mm-450mm Frame Kit
Forward F722 F7 OSD Flight Controller Board
MPU: MPU6000
CPU: STM32F722 RET6
Input Voltage: 3-6S Lipo
Built-in Betaflight OSD to adjust PID
Built-in LED Controller
BEC Output: 5V 3A ; 9V 2A
Black Box: 16M
Size: 37.3x37.3mm
Mounting Hole: 30.5x30.5mm
M3 Weight: 7.6g
UARTS: 5
UART1: Receiver ( SBUS/IBUS/DSMX/R9MM/CRSF)
UART2:
UART3: VTX
UART4: GPS
UART6: ESC Telemetry
Forward 60A BLheli_32 32bits 4in1 ESC
CPU: STM32F051
Con. Current: 60A
Burst Current: 65A (10S)
Input Voltage: 3-6S Lipo
BEC: NO
Supported Protocols: DSHOT1200/600/300/150, ONESHOT125/42
Mounting Hole: 30.5x30.5mm, M3
Size: 45x40x6.5mm
Weight: 18g
Package Included:
1x F7 Flight Controller
1x 60A BL_32 4In1 ESC
8x Anti-vibration Ball
1x bag of Screws
1x bag of Cables
1x Capacitor
1x Connector
