30.5x30.5mm iFlight SucceX F4 TwinG Dual Tyro Flight Controller AIO OSD BEC Support SmartAudio for RC Drone FPV Racing - 41.00 €

30.5x30.5mm iFlight SucceX F4 TwinG Dual Tyro Flight Controller AIO OSD BEC Support SmartAudio for RC Drone FPV Racing
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


iFlight SucceX F4 TwinG Dual Tyro Flight Controller AIO OSD BEC Support SmartAudio for RC Drone

Specification:
Brand Name: iFlight
Model: SucceX F4 TwinG
Item Name: Dual Gyro F4 Flight Controller AIO OSD BEC
Input Voltage: 2-6S (5-36V)
MCU: STM32F405R6T6
IMU: Twins IC2689,Twins Gyros built-in (SPI)
OSD: AT7456E
Blackbox: Blackbox logging device
BEC: 5V@ 3A
Firmware: Betaflight/INAV
Target: STM32F405
FC: IFRC/IFF4_TWIN_G(STM32F405)
Size: 36x36mm
Mounting Hole: 30.5x30.5mm ( φ4mm with Grommets φ3mm)
Weight: 6.3g
- 5X Uarts (1 2 3 4 5) with build-in inversion
- 8X Dshot/Proshot/Oneshot output
- 8X individual ESC power/ signal pads
- 1X Group of Gnd/Vbat/M1/M2/M3/M4/Cur/TX
- Smart audio & Tramp VTX protocol: Support (IRC Tramp)
- WS2812 led Strip: Suppor
- Beeper: Support
TwinG Gyro Setup
-The Betaflight target's default setting is ‘gyro_to_use = both’ / Gyro fusion is active!
-To check the current setting, please use CLI and type ‘get gyro’ to find the responding entry.
-Change the settings with ‘set gyro_to_use = ’ and type ‘save’.
-To get the most reliable performance or encounter noise, oscillation and bent props: Please use the default setting ‘both”.
-For Single Gyro use, please use the debugging options to find and tune for the cleaner gyro, but lose the dynamic fusion and averaging.
-BF offers the following dual gyro debug options: dual_gyro_raw, dual_gyro, dual_gyro_diff, dual_gyro_combined.
-BlackboxLog explorer graph: dual_gyro_raw Debugging = [0] Roll Gyro1, [1] Pitch Gyro1, [2] Roll Gyro2, [3] Pitch Gyro2.
-The displayed graph will show the Gyro_Raw reading (no filters applied), both gyros can be compared.

Package Included:
1x F4 Flight Controller Board
4x silicon grommets M4 to M3
1x 8P Cable
