Description:
Brand: Racerstar
Product: DS5601MG Digital Servo
Operating Voltage: DC3.7-5.5V
Operating Speed (3.7V): 0.13sec/60°
Operating Speed (4.2V): 0.12sec/60°
Operating Speed (5.5V): 0.10sec/60°
Stall Torque (3.7V): 0.58kg.cm
Stall Torque (4.2V): 0.70kg.cm
Stall Torque (5.5V): 0.89kg.cm
Dead Band: 1μs
Working Frequence: 1520μs / 300hz
Rotation: 120°
Gear: Metal Gear
Motor: Coreless Motor
Dimensions: 19.8x8.2x20MM
Connector Wire Length: JR150 mm
Operating Temperature Range: -20 to + 60°C
Weight: 5.6g
Application: For RC Airplane
Package Included:
4 * Racerstar DS5601MG Digital Servo
4 * Servo Arm Set
