5.2g Beitian BS-200 Micro GPS Antenna Module FLASH TTL Level 9600bps for RC Drone FPV Racing Multirotors - 10.00 €

5.2g Beitian BS-200 Micro GPS Antenna Module FLASH TTL Level 9600bps for RC Drone FPV Racing Multirotors
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


5.2g Beitian BS-200 Micro GPS Antenna Module FLASH TTL Level 9600bps for RC Drone FPV Racing Multirotors

BS-200 datasheet, please click here.

Specification:
Item name: Beitian BS-200 micro GPS antenna module
Dimensions: 20mm*20mm*6mm
Weight: 5.2g
Connector: 1.00mm 4pins connector
Built-in Flash, TLL level, 9600, 1Hz output, NMEA-0183 protocol output

Electrical Characteristics
Chipset: G7020-KT
Frequency: GPS L1, SBAS L1, QZSS L1
Receiving Format: GPS, SBAS, QZSS
Channels: 56 Searching Channel

Sensitivity
Tracking: -162dBm
Reacquisition: -160dBm
Cold Start: -148dBm

Accuracy
Position Horizontal: 2.0 m (Typical Open Sky)
Velocity: 0.1m/sec 95% (SA off)
Timing: 1us synchronized to GPS time

Acquisition Time
Cold Start: 29s
Warm Start: 25s
Hot Start: 1s

Data Output
Support Rate: 4800bps to 921600bps, Default 9600bps
Data Level: Default TTL Level
Data Protocol: NMEA-0183 or UBX, Default NMEA-0183
NMEA Message: RMC, VTG, GGA, GSA, GSV, GLL
Update Rate: 1Hz-10Hz, Default 1Hz
FLASH: 4M FLASH, Store the configuration permanently

Operational Limits
Altitude: 50,000m Max
Velocity: 515m/s Max
Acceleration: Less than 4g

Power Consumption
VCC: DC Voltage 3.0V-5.5V, Typical: 5.0V
Current: Capture [email protected]

Environment
Operating Temp: -40 °C ~ +85°C
Storage Temp: -40°C ~ +105°C

Built-in LED
TX LED: blue. The data output, TX LED flashing
PPS LED: red. PPS LED not bright when GPS not fixed, flashing when fixed

Package included:
1x Beitian BS-200 GPS antenna module
