10KM Ultra Long Range RF900Mini 915MHz RFD 900U 3DR Telemetry Radio Modem
Appearance
Size: 19.0 mm (wide) x 30.4 mm (long) x 4.5 mm (thick) ,Including RF Shield and maximum connector extremeties
Weight: 2.7g
Mounting: 2 x M1.5 screws
Interface
RF: 2 PCS u.FL/IPX, TTL
Connector : DF13, 8CH
Specification
Frequency Range : 902 - 928 MHz (USA)
Output Power: 100mW (+20dBm), controllable in 3dB steps
High Gain : >24dB
Long Distance : >10km
SAW filter
128kB flash memory,8kB RAM
Air Data transfer rates:
4, 8, 16, 19, 24, 32, 48, 64, 96, 128, 192 and 250 kbit/sec ( User selectable, 64k default )
UART data transfer rates:
2400, 4800, 9600, 19200, 38400, 57600, 115200 baud ( User selectable, 57600 default )
Receive Sensitivity:
<-111dBm at 9.6kpbs,
<-107 dBm at 64kbps,
<-105dBm at 129kbps (air serial speed)
Power Supply: +5V nominal(+3.5 V min, +5.5 V max)
~190mA TX +20dBm
~230mA peak TX +20dBm
~77mA RX
Temp. Range: -40 to +85 deg C
Package Included
2 x RF900MINI Module
Temp. Range: -40 to +85 deg C
