BETAFPV ExpressLRS ELRS868/915MHz Nano Long Range Micro TX Module Compatible FrSky X Lite TBS Tango 2 for RC Drone
OVERVIEW:
BETAFPV Nano RF TX module is based on the ExpressLRS project, an open-source RC link for RC applications. ExpressLRS aims to achieve the best possible link performance in both speeds, latency, and range. This makes ExpressLRS one of the fastest RC links available while still offering long-range performance.
Specifications:
Brand Name: BETAFPV
Item Name: 868/915MHz Nano TX Module
Weight: 29g (only module)
Weight: 35g (with antenna)
Weight: 34g (with moxon antenna)
Packet refresh rate: 25Hz/50Hz/100Hz/200Hz (915MHz/868MHz)
RF output power: 100mW/250mW/500mW
Frequency bands (Nano RF Module 915MHz/868MHz version): 915MHz FCC/868MHz EU
Input voltage: 5V~12V
USB port: Type-C
The RF TX module output power and LED indication as shown below:
| LED Color | RF output power |
| Blue | 100mW |
| Purple | 250mW |
| Red | 500mW |
Package Included:
1 x TX Module (868/915MHz Optional)
1 x Moxon Antenna
1 x User Manual
