CUAV VMR32 5.8G 32CH OTG FPV Receiver Mobile Phone Gound Station For Android Smartphone iPad PC
It can be power supply by smartphone or external battery. If power supply by smartphone was not enough, the receiving distance will be influenced .
Description: Download
Resolution : 640*480 30fps
Working Temp.: -10â-+60â
Working Voltage : USB5V/9v-32v
Working Current : USB 5V 250mA
Color : Gold,Gray,Black
Size : 43mm x 56mm x 11mm(withou antenna)/80mm(antenna height)
Weight : 56g
Connector : RP-SMA
Features:
5.8G 32CH Frequency
Auto Search Frequency
Equip with LED Displayer
Compatible with CUAV 5.8G Transmitter and other 5.8G Transmitter
Support Anderson iPad, PC ,smartphone which have OTG and AV monitor
Adopt CNC shell, sturdy construction, anti-inteference, bettery for cooling.
Built in 32 bit MCU
Auto save channel when it power off.
Operation:
Smarphone:
1. Android smartphone install the video software
2. Connect VMR32 via OTG cable(no need extra power supply)
3. When the VTX working normal, press the receiver button to search the frequency and see the live image.
PC:
1. Connect PC with USB
2. Open AMCAP camera software or MP goundstation
3. When the VTX working normal, press the receiver button to search the frequency and see the live image.
AV Monitor :
1. Solder the cable, customise the AV connector on monitor, power supply for receiver 3-6S
2. When the VTX working normal, press the receiver button to search the frequency and see the live image.
Package Included :
1 x CMR32 Receiver
1 x Clover Antenna
1 x USB Data Cable
1 x OTG Cable
