Description:
Item Name: DasMikro 10 Channel Bluetooth RC Receiver
Channels: 10ch
Power: 3.7~9.6V DC
Size (W*H*D): 29 x 28 x 8mm
Weight: 4g
Features:
This is a 10 channel Bluetooth RC receiver designed to work with Android app RoboRemo. It has 10 channel standard RC PWM signals (1ms-2ms) output. You could use your Android mobile phone to control this receiver like the traditional RC transmitter system works. This Bluetooth RC receiver could replace your standard RC receiver easily and you do not need a transmitter anymore. With your Android mobile phone and Roboremo App, nothing is impossible.This RC receiver use Bluetooth 2.0 technology, the control distance is around 10 meters with the onboard antenna.
Android APP Roboremo:
You could find latest version Roboremo app in Google Play. There is one free version and one paid version. In free version you could use maximum 5 channels. We also provide RoboRemo-1.9 version apk file for testing 10 channels. If you like this app please purchase the app from Google Play.
Free version download link, check here
Paid version download link:check here
User download link including APK,Interface , User Manual:check here
Pair:
Bluetooth ID is HC-06, password 1234. You need to pair your mobile phone with the Bluetooth module before using this receiver.
App and Receiver Connection:
menu -> connect -> Bluetooth -> select device -> select port 1
Failsafe:
If the receiver is out of range or lost connection with the mobile phone, all 10 channels will output the middle position (1.5ms).
Package Included:
1 x DasMikro 10 Channel Bluetooth RC Receiver
