Specifications:
AIRCRAFT
Weight: 7.25lbs ( 3290g, including two batteries, without gimbal and camera )
Diagonal distance ( propeller excluded ): 18 inches ( 605mm, Landing Mode )
Max. takeoff weight: 8.82lbs ( 4000g )
Max. takeoff sea level: 1.55 miles ( 2500m ); 3.1 miles ( 5000m with specially-designed propeller )
Max. flight time: approx. 27mins ( with Zenmuse X4S )
Max. tilting angle: P-mode: 35 degree ( Forward Vision System enabled: 25 degree ); A-mode: 35 degree; S-mode: 40 degree
Max. ascent speed: P-mode / A-mode: 16.4ft/s ( 5m/s ); S-mode: 19.7ft/s ( 6m/s )
Max. descent speed: vertical: 13.1ft/s ( 4m/s ); tilt: 13.1 - 29.5ft/s ( 4 - 9m/s ), default tilt: 13.1ft/s ( 4m/s ), can be set in-app
Max. speed: 67 mph / 108 kph
GPS hovering accuracy: vertical: ï¼/ - 1.64ft ( 0.5m ) or ï¼/ - 0.33ft ( 0.1m, Downward Vision System enabled ); horizontal: ï¼/ - 4.92ft ( 1.5m ) or ï¼ / - 0.98ft ( 0.3m, Downward Vision System enabled )
Operating temperature: -4 to 104 Deg.F ( -20 to 40 Deg.C )
DOWNWARD VISION SYSTEM
Velocity range: less than 32.8ft/s ( 10m/s ) at height of 6.56 feet ( 2m )
Altitude range: less than 32.8 feet ( 10m )
Operating range: less than 32.8 feet ( 10m )
Operating environment: surfaces with clear patterns and adequate lighting ( more than 15 lux )
Ultrasonic sensor operating range: 0.33 - 16.4ft ( 10 - 500cm )
Ultrasonic sensor operating environment: non-absorbing material, rigid surface ( thick indoor carpeting will reduce performance )
UPWARD INFRARED SENSOR
Obstacle sensing range: 0 - 16.4ft ( 0 - 5m )
FOV: + / - 5 degree
Operating environment: large-size non-reflective obstacles
CHARGER
Voltage: 26.1V
Rated power: 180W
CHARGING HUB
Input voltage: 26.1V
Input current: 6.9A
GIMBAL
Angular vibration range: + / - 0.01 degree
Controllable range: pitch: -130 to +40 degree; roll: + / - 20 degree; pan: + / - 320 degree
Max. controllable speed: pitch: 90 degree/s; roll: 90 degree/s; pan: 90 degree/s
FORWARD VISION SYSTEM
Obstacle sensing range: 2.3 - 98.4ft ( 0.7 - 30m )
FOV: horizontal: 60 degree; vertical: 54 degree
Operating environment: surfaces with clear patterns and adequate lighting ( more than 15 lux )
REMOTE CONTROLLER
Operating frequency: 2.400 - 2.483GHz; 5.725 - 5.850GHz
Max. transmitting distance:
2.4GHz - FCC: 4.3 miles ( 7km ); CE: 2.2 miles ( 3.5km ); SRRC: 2.5 miles ( 4km ) ( unobstructed, free of interference )
5.8GHz - FCC: 4.3 miles ( 7km ); CE: 1.2 miles ( 2km ); SRRC: 3.1 miles ( 5km )
EIRP:
2.4GHz: 26dBm ( FCC ); 17dBm ( CE ); 20dBm ( SRRC )
5.8GHz: 28dBm ( FCC ); 14dBm ( CE ); 20dBm ( SRRC )
Battery: 6000mAh 2S LiPo
Output power: 9W ( cannot supply power for mobile device )
USB supply power: iOS: 1A at 5.2V ( max. ); Android: 1.5A at 5.2V ( max. )
Operating temperature: -4 to 104 Deg.F ( -20 to 40 Deg.C )
INTELLIGENT FLIGHT BATTERY
Capacity: 4280mAh
Voltage: 22.8V
Battery type: 6S LiPo
Energy: 97.58Wh
Net weight: 515g
Charging temperature: 41 to 104 Deg.F ( 5 to 40 Deg.C )
Operating temperature: -4 to 104 Deg.F ( -20 to 40 Deg.C )
Max. charging power: 180W
Specification
General |
Brand: DJI
Type: Quadcopter Model: INSPIRE 2 Features: 360 Degree Surround,5.8G FPV,Barometer Set Height,GPS,Radio Control Functions: Automatically Following,Camera,Forward/backward,FPV,GPS location tracking,Hover,Level Calibration,One Key Automatic Return,One Key Landing,One Key Taking Off,Point of Interest,Sense and Avoid,Sideward flight,Sport Mode,Tap to Fly,Turn left/right,Up/down,Visual Tracking,Waypoints,With light Diagonal Length: 18 inches / 605mm in Landing Mode ( excluding propellers ) Max Speed: 67 mph / 108 kph Max Ascent Speed: P-mode / A-mode: 16.4ft/s ( 5m/s ); S-mode: 19.7ft;s ( 6m/s ) Max Descent Speed: vertical: 13.1ft/s ( 4m/s ); tilt: 13.1 - 29.5ft/s ( 4 - 9m/s ), default tilt: 13.1ft/s ( 4m/s ), can be set in-app Hover Accuracy: vertical: ï¼/ - 1.64ft ( 0.5m ) or ï¼/ - 0.33ft ( 0.1m, Downward Vision System enabled ); horizontal: ï¼/ - 4.92ft ( 1.5m ) or ï¼ / - 0.98ft ( 0.3m, Downward Vision System enabled ) Built-in Gyro: 6 Axis Gyro Night Flight: Yes Material: Alloy,Carbon Fiber,Electronic Components Kit Types: RTF Level: Advanced Level |
|---|---|
Connectivity |
Remote Control: 2.4GHz Wireless Remote Control
Channel: 11-Channels Mode: Mode 2 (Left Hand Throttle) Detailed Control Distance: 7km Compatible with Additional Gimbal: Yes FPV Distance: FCC: 4.3 miles ( 7km ); CE: 1.2 miles ( 2km ); SRRC: 3.1 miles ( 5km ) Transmitter Power: Built-in rechargeable battery Model Power: Rechargeable Battery |
Battery |
Battery: 22.8V 4280mAh 6S LiPo
Flying Time: About 27mins Charging Time (h): About 3.5 hours Battery Weight: 515g |
Camera |
Camera Pixels: 16MP
Video Resolution: 5.2K; 4K |
Dimension and Weight |
Package weight: 5.000 kg
Package size (L x W x H): 65.00 x 45.00 x 25.00 cm / 25.59 x 17.72 x 9.84 inches |
Package Contents |
Package Contents: 1 x Aircraft Body, 1 x Transmitter, 8 x Propeller, 2 x Intelligent Flight Battery, 1 x Battery Charger, 1 x Charging Hub, 1 x Power Cable, 1 x USB Cable, 1 x 16GB Micro SD Card, 1 x Vision System Calibration Plate, 3 x Gimbal Damper, 1 x Set of Propeller Mounting Plates, 1 x Carrying Case, 4 x Battery Insulation Sticker, 1 x Set of English-Chinese Manuals |
