Description:
Brand Name: E-Do Model
Item Name: Sky Eye
Version: Single Pusher Version
Material: EPO
Wingspan: 1890mm
Length: 1480mm
Wing Area: 44dm²
Take-off Weight: 2500g - 3500g
Recommended Parts For Sky Eye (Not Included):
Motor: 2814 KV900, Click Here
ESC: 60A, Click Here
Servo: 9g x4, 2 more for the optional flaps, Click Here
Propeller: 11-12 inch, Click Here
Battery: 4S 14.8V 10000mAh
Charger: Balance Charger, Click Here
Radio System: 2.4G 4-6CH, Click Here
Features:
- EPO material, lightweight and durable.
- Excellent flight stability, good gliding performance and long flying time.
- Adopts modular structure design, easy installation and quick release design. The wing, tail pipe and horizontal tail are detachable. No glue is required.
- The front and rear tubes of the carbon fiber tube with front and rear double butt joints are respectively Φ14, Φ8, preventing the front and rear of the wing from twisting and increasing the wing strength.
- The layout structure of the fuselage compartment is divided into 3 layers, and there is a large space to install electronic equipment. Get rid of the troubles of wiring.
- The tail pipe is wound with 3K fiber cloth for durability.
- The tail pipe is machined with aluminum pipe clamps. You can adjust the length of the tail pipe according to your actual situation.
- The aircraft can be upgraded to a deep stall landing function. The deep stall function is an optional feature.
- With metal servo horn and there is no need to worry about breaking and leaking.
- The cover of the aircraft is fixed with a bayonet. Disassembly and assembly is very convenient.
- Reserve the rudder surface of the flaps.
- Reserve the VTX installation platform and GPS installation slot.
Note:
KIT version, all the electronic devices are not included.
Glue is not included.
English Manual, Click Here
Package Included:
1x E-Do Model Sky Eye 1890mm Single Pusher Version EPO FPV Glider KIT
