Specification:
Brand name: Eachine
Item name: AIO F4 Flight Controller 12A 2-4S ESC Frsky Receiver Board
| Flight controller |
MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000(SPI connection) Board size: 28.5 * 28.5MM Power supply: 2-4S battery input (DC 8V-17V) Built-in 12A(each) Blheli_S 4in1 ESC Dshot600 ready Built-in Frsky D8/D16 SPI receiver Built-in 2.4G Power Amplification Built-in Betaflight OSD(SPI Control) Built-in Current meter Max 70A Built-in 5V 1.5A BEC Built-in voltage detection Firmware target: MATEKF411RX |
| Onboard 4in1 ESC |
MCU upgraded to EFM8BB21 Power supply: 2-4S LiPo/LiPo HV (7v/17v) Current: 12A continuous peak 15A (5 seconds) Support BLHeliSuite programmable Factory firmware: F_H_40_REV16_7.HEX Default protocol: DSHOT600 |
| Internal Frsky NON-EU receiver Version |
SPI BUS receiver Frsky D8/D16 compatible Compatible Non EU transmitter both D8 mode and D16 mode Channels: 8ch/16ch Dual antenna Failsafe support No ground interference ( Transmitter and receiver 1 m from the ground): 400m |
Package Included:
1 x AIO F4 Flight Controller 12A 2-4S ESC Frsky Receiver Board
