Eachine Wizard X220 FPV Racing Drone Blheli_S F3 6DOF 2205 2300KV Motors 5.8G 40CH 200MW VTX 700TVL Camera ARF Version
Note:
This is the ARF version that comes without battery, charger, receiver or remote control.
| Item | Specification | Features |
| Eachine Wizard X220 |
Wheelbase: 220mm GMachine arm: 4mm carbon fiber Flying times: 12 minutes Weigh: 364g (without battery) Take off weigh: 535g |
Compatible with max 5 inch propeller Compatible with 2206, 2208 motor Can be used with 4S/3S battery With Seft-protection function With direction indicator LED Inclined motor base design, fast speed Removable protection motor base |
| 2205 2300KV Motor |
KV : 2300 Propeller : 5 inch |
|
| Eachine 20A BLHELI_S ESC |
Item name : 20A BLHELI_S ESC Con.Current : 20A Peak Current(10s) : 25A Input Voltage : 2-4S BEC : No Programming : YES Firmware : Blheli_S Weight :7.9g Size(PCB) : 27*12mm |
|
| 700TVL Camera |
Power supply : 3.6-5.5V (powered off TX) Power consumption : 60mA @5V Imager : 1/3 Angle : 127° diagonal FOV, 110° horizontal FOV FPV tuned light handling System : PAL Lens : 2.8mm IR coated FOV : 127°diagonal 110°horizontal (ideal for fixed camera) Operation temperature : -20 to 70°C Square : 29 X 29 X 23.5mm Lens extrude (LxDia) : 15mm X 14mm Weight : 12g |
|
| 5.8G 200mw 40ch Transmitter |
Modulate : Wideband FM Modulate Video Format : NTSC/PAL Output Impedance : 50 Ohm Output Power : 23-24dBm Channel: 40 CH Operating Voltage : 7V-24V Supply Current : 190mA Operating Temperature : -10~85â Video Band Width : 0~8.0 MHz Audio Carrier Frequency : 6.5 MHz Video Input Level : 0.8~1.2 Vp-p Video Input Impedance : 75 Ohm Audio Input Level : 0.5~2.0 Vp-p Audio Input Impedance : 10K Ohm Connector: RP-SMA Female (Inner needle) Antenna connector: RP-SMA Male (Inner hole) Dimension: 40mm x 23mm x 8mm Weight: 7.3g |
|
| Flight controller |
F3 6DOF, betaflight 2.9.1 version |
|
| Kingkong 5040 3-Blade Propeller |
Color: purple Quantity: 10 Pairs Mounting Hole: 5mm Weight: 137g Size: 140*140*65 mm |
|
Package included:
1 x Eachine Wizard X220
2 x 2205 KV2300 brushless motor CW
2 x 2205 KV2300 brushless motor CCW
4 x Eachine 20A BLHELI_S ESC
10 x Kingkong 5040 3-blade propeller purple CW
10 x Kingkong 5040 3-blade propeller purple CCW
1 x F3 6DOF flight controller
1 x 700TVL camera
1 x 5.8G 40CH 200mw transmitter
1 x Antenna
1 x Battery strap
2 x Wrench
