Main Features:
â High speed power system featuring RS1106 6000KV motor and the AIO flight controller system with F3 FC + 4-in-1 12A BLHeli - S ESC
â 112mm carbon fiber frame, only weighs 89g, anti-crash
â Pre-tuned Betaflight firmware for optimized flight performance
â OSD integrated with low voltage detection
â 5.8G 40CH 25mW / 200mW switchable power VTX
â Compatible with EMAX transmitter / goggles / accessories
â Strong 3mm arms with lower profile arms to reduce drag
â 650TVL micro CCD camera with tuned profiles for different light condition. CCD is preferred by more pilots over CMOS for its better handling of high contrast lighting
F3 Flight Controller
Firmware: Betaflight 3.2.2 OMNIBUS
CPU: STM32F303 MCU
IMU: MPU6000
OSD: BetaFlight OSD
Support cells: 3 - 4S
4-in-1 ESC
Firmware: BLHeli - S
Continuous current: 4 x 12A
Burst current: 4 x 15A
Support cells: 2 - 4S
Support protocol: Dshot150 / Dshot300 / Dshot600 / Oneshot / Multishot
â High speed power system featuring RS1106 6000KV motor and the AIO flight controller system with F3 FC + 4-in-1 12A BLHeli - S ESC
â 112mm carbon fiber frame, only weighs 89g, anti-crash
â Pre-tuned Betaflight firmware for optimized flight performance
â OSD integrated with low voltage detection
â 5.8G 40CH 25mW / 200mW switchable power VTX
â Compatible with EMAX transmitter / goggles / accessories
â Strong 3mm arms with lower profile arms to reduce drag
â 650TVL micro CCD camera with tuned profiles for different light condition. CCD is preferred by more pilots over CMOS for its better handling of high contrast lighting
F3 Flight Controller
Firmware: Betaflight 3.2.2 OMNIBUS
CPU: STM32F303 MCU
IMU: MPU6000
OSD: BetaFlight OSD
Support cells: 3 - 4S
4-in-1 ESC
Firmware: BLHeli - S
Continuous current: 4 x 12A
Burst current: 4 x 15A
Support cells: 2 - 4S
Support protocol: Dshot150 / Dshot300 / Dshot600 / Oneshot / Multishot
Specification
General |
Brand: EMAX
Type: Frame Kit Version: BNF |
|---|---|
Motor |
Motor Type: Brushless Motor
KV: 6000 Maximum Thrust: 0.2kg |
Flight Controller |
Flight Controller Type: F3 |
Remote Controller Specifications |
Control Distance: Above 800m
Detailed Control Distance: About 800m Protocol: FrSky |
Camera |
Video Resolution: 650TVL
Sensor: CCD |
Electronic Speed Controller |
Firmware: BLHeli-S
Functions: DShot150,DShot300,DShot600,Multishot,Oneshot125,Oneshot42 Continuous Current: 4 x 10A Burst Current: 4 x 15A Input Voltage: 2 - 4S |
Battery |
Battery (mAh): 800mAh / 850mAh 50C / 75C lithium battery ( not included )
Battery Voltage: 4S |
Dimension and Weight |
Product weight: 0.0890 kg
Package weight: 0.1650 kg Product size (L x W x H): 13.50 x 13.50 x 4.00 cm / 5.31 x 5.31 x 1.57 inches Package size (L x W x H): 21.00 x 12.80 x 5.00 cm / 8.27 x 5.04 x 1.97 inches |
Package Contents |
Package Contents: 1 x Drone, 1 x English Manual, 8 x Propeller, 1 x Screw Package |
