F3 EVO Cleanflight Flight Controller for Multirotor Racing w/ 4G MicroSD
Operations Tutorial: http://files.banggood.com/2016/08/Produce.mpg
Specification:
Item name: F3 EVO Flight Controller
Weight: 5 grams
36x36mm board with 30.5mm mounting holes
STM32F303 CPU, 72Mhz inc FPU
MicroSD card slot (SD/SDHC, upto 32GB)
MPU9250 accelerometer/gyro/compass (connected via SPI)
BMP280 barometer
1 IR LED and unique code for race transponder
MicroUSB socket for configuration and ESC programming
3 LEDs for 5V, 3V and STATUS (Green, Blue, Red)
Supplied with straight and right-angled pin headers
Copper-etched Cleanflight logo
8x 3pin though-holes for pin headers for ESC/Servo connections
1x 2pin though-holes for pin headers for UART1 RX/TX
1x 6pin though-holes for pin headers for UART2/PPM/Telemetry/LiPo (for standard SerialRX/SBus/PPM lead)
1x 4pin though-holes for pin headers for UART3
1x 6pin though-holes for pin headers for IR LED/LED Strip, RSSI, Current Monitoring, and Buzzer connections
1x 3pin though-holes for JST-ZH connector for Spektrum Satellite receivers (connector supplied).
1x 4pin top mounted, JST-SH socket for I2C
1x 4pin top mounted, JST-SH socket for UART2/PPM
1x 4pin bottom mounted JST-SH socket for SWD debugging
1x 2pin though-holes for BOOT jumper
Feature:
Feature:
1. Sonar
Sonar support for precision low-altitude hold.
2. Buzzer
Buzzer port for audible warnings and notifications.
3. I2C Port
I2C port always powered, perfect for external sensors or always-on OLED Screen.
4. OneShot ESC
Full support for OneShot ESCs for easy PID tuning and a sharper response.
5. Battery Monitoring
Built in battery voltage monitoring, input for additional current monitoring.
6. Developer Friendly
Developer friendly debugging port (SWD) and boot mode selection, unbrickable bootloader.
7. Dedicated ports for PPM/SBus/SumH/etc for easy connections. Socket for plug and play Spektrum Satellite receiver.
8. Programmable LEDs
Output for multi-colored LED strips - great for FPV racing, line-of-sight flying orientation and night flying.
9. Jaw-Dropping Flight Performance
The F3EVO uses advanced processor, sensor and software technologies to make your aircraft fly like it's on rails.
The F3EVO flight-controller and the Cleanflight software enables the precision flying you need for fast FPV racing.
10. Next-Generation CPU
The F3EVO has an ARM Cortex-M4 72Mhz CPU with Math co-processor (FPU) for efficient flight
calculations that gets more done in less time.Loop times up to ~2x as fast as previous-generation STM32F1 based boards.
calculations that gets more done in less time.Loop times up to ~2x as fast as previous-generation STM32F1 based boards.
11. SPI sensor connection
The gyroscope and accelerometer sensors are connected to the fast SPI bus.
This enables the software to get more data even quicker to help stabilize your aircraft even better
This enables the software to get more data even quicker to help stabilize your aircraft even better
12. Race Timing Transponder
The F3EVO features a race transponder system for recording your lap times.
Each board comes with a special transponder code to identify you at race events. Compatible with i-LAP receiver systems.
Each board comes with a special transponder code to identify you at race events. Compatible with i-LAP receiver systems.
13. MicroSD
The F3EVO is the first and only standard sized board for Cleanflight that features a MicroSD card socket for logging.
Supports MicroSD/SDHC up to 32GB - just leave one in and log every flight!
Supports MicroSD/SDHC up to 32GB - just leave one in and log every flight!
14. USB
USB socket to configuration of flight controller and for pass-though configuration of BlHeli ESCs.
USB socket is not shared with any of the 3 serial ports. No more unplugging your OSD when configuring
15. Configurable
The F3EVO runs Cleanflight which can be configured to suit your needs using a cross-platform GUI (Windows/OSX/Linux).
16. Small and lightweight
The F3EVO has a standard 36x36mm form-factor with 30.5mm mounting holes on a thick PCB for durability.
17. Stackable
The F3EVO is a stackable design. Connect an OSD or PDB directly under the board for a super-tidy and wire-free installation.
Stackable designs are proven to be more durable in a crash.
18. Broad RC receiver support
Supports SBus, SumH, SumD, Spektrum1024/2048, XBus, PPM. No external inverters required (built-in),
receiver powered via flight battery or USB for easy configuration.
receiver powered via flight battery or USB for easy configuration.
19. Cleanflight logos and stickers
The F3EVO features a copper-etched Cleanflight logo so you can show your support!
Each purchase direct from the Seriously Pro shop also comes with stickers! (when available)
20. GPS Ready
With a full-set of sensors (Accelerometer, Gryoscope, Compass and Barometer) each F3EVO is capable of GPS Navigation
Available in Cleanflight soon, New GPS features under active development.
CleanFlight Software Features:
The F3 runs Cleanflight and is configured using the Cleanflight Configurator. It has a stack of great features, such as these:
1. 3 primary flight modes: Acrobatic, Angle and Horizon
2. Extensive control and switch configuration
3. Telemetry Support (HoTT, FrSky, SmartPort, etc)
4. Battery Monitoring and Warnings
5. Signal Strength Monitoring (RSSI)
6. Failsafe system
7. Altitude Hold Mode
8. Heading Hold Mode
9. In-flight tuning
10. Customizable LED colors
11. Android phone support (via EZ-GUI GCS)
Package included:
1 x F3 EVO Flight Controller
1 x MicroSD card socket and pin headers
1 x Micro SD card 4G
