Overview:
The Piper PA-18 Super Cub is a two-seat, single-engine monoplane. It was developed from the Piper PA-11. In close to 40 years of production, over 9,000 were built. Super Cubs are commonly found in roles such as bush flying, banner towing and gliding towing.
As a relative of the popular 1400mm J-3 Cub, the 1700mm PA-18 Super Cub retains great flight characteristics while offering increased power and wingspan.
Thanks to its functional flaps, high-lift airfoil, rugged landing gear and oversized balloon tires- the 1700mm PA-18 Super Cub has impressive short take-off and landing (STOL) performance, allowing it to operate from just about any terrain.
Utilizing the latest FMS hardware and design, the 1700mm PA-18 Super Cub has pre-installed ball-link type pushrods, integrated servo connectors in the wing structure and can be assembled very easily using no glue at all.
For pilots wanting to get the genuine bush-plane experience, the PA-18 Super Cub can be equipped with floats.
Versatile, fun and exceptionally relaxing to fly- the 1700mm PA-18 Super Cub is a great addition to any fleet!
Specifications:
Brand Name: FMS
Item Name: PIPER PA-18 SUPER CUB
Material: EPO
Wingspan: 1700mm
Overall Length: 1136mm
Wing Area: 42dm²
Wing Load: 50g/dm²
Flying Weight: ~2100g
Motor Size: 3541-KV750
ESC: 45A XT60 Plug
Servo: 17g*6
Prop Size: 12*7.5, 2-blade
CG (center of gravity): 80-85mm from leading edge
Aileron: Yes
Flaps: Yes
Retracts: No
Approx. Flying Duration: 4-6 minutes
Minimum Age Recommendation: 14+
Experience Level: Intermediate
Recommended Environment: Outdoor
Assembly Time: 40 minutes
Is Assembly Required: Yes
Recommended Parts For 1220mm Ranger (Not Included):
Battery: 4S 14.8V 2200-2600mAh 35C LiPo, Click Here
Charger: Balance Charger, Click Here
Radio: 2.4G 6 Channel, Click Here
Features:
- Powerful 3541- 750KV Outrunner motor with Predator 45A ESC provides adequate thrust for any situation.
- CNC metal landing gear structure for less-than-perfect landings.
- 6.25-inch oversized balloon tires for all-terrain operations.
- STOL capable (Takes off in less than 3m/10ft)
- Pre-installed navigation and landing lights
- Two-piece wing and horizontal stabilizer for easy transportation
- High-strength carbon fiber wing spars
- Integrated servo connectors
- Screw-together assembly
- Large battery bay
- Ball-linked pushrods for increased precision
- Tough two bladed Nylon propellers
- Functional flaps
- Optional floats and stainless-steel struts
Note: PNP version doesn't include battery,charger,transmitter and reciver.
English Manual, Click Here
Package Included:
1x FMS PIPER PA-18 SUPER CUB 1700mm Wingspan EPO RC Airplane PNP With Floats
