FrSky R9M Lite 900MHz Transmitter Module Up to 1W RF Power with R9 MX OTA ACCESS Long Range Receiver Combo with Mounted Super 8 and T antenna - 49.00 €

FrSky R9M Lite 900MHz Transmitter Module Up to 1W RF Power with R9 MX OTA ACCESS Long Range Receiver Combo with Mounted Super 8 and T antenna
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


;

FrSky R9M Lite 900MHz Transmitter Module Up to 1W RF Power with R9 MX OTA ACCESS Long Range Receiver Combo with Mounted Super 8 and T antenna


Description:

Brand Name: FrSky

Item Name: R9M Lite Module with R9 MX Receiver

Version: FCC 915MHZ/LBT 868MHZ


R9M Lite Overview:

R9M Lite module is a 900MHz frequency system which is specially designed for FrSky Taranis X-Lite transmitter. This being the "Lite" version of the R9 series works perfectly with all receivers in the R9 series. In addition, it gets supers low latency and high precision thanks to the upgraded digital interface and high-speed data transmission. The R9M Lite has the extreme performance with the ability to achieve long distances with one RF power output at 100mW.


Specification:

Dimension: 62.4mm × 30mm×14.5mm (L×W×H)

Weight: 20g

Number of channels: 16 channels

Operating Current: [email protected]

RF Operating Frequency: 900MHz/868MHz

RF Power (Non-EU): 100mW (with telemetry)

RF Power (EU): 25mW (with telemetry) /100mW (without telemetry)

RF Power (Flex):100mW (with telemetry)

Compatibility: R9 series receivers


Features:

Firmware upgradable on Taranis X-Lite

Telemetry data transmission supported

Long Range, Low Latency and High precision RC system


R9 MX Overview:

The R9 MX is the enhanced versions of the previous R9 MM/Mini series long-range capable receivers, equivalent in size and weight equipped with a robust detachable Ipex1 antenna connector.


The R9 MX takes features from the previous R9 Mini and R9 MM making it compatible with more external devices by providing an Inverted S.Port output and supporting the redundancy function. Additionally, it retains soldering points to connect 4 PWM channels. The enhanced design proves to be more durable, and in conjunction with the latest ACCESS firmware, the two are now synchronized and we are able to unlock the true potential of the ACCESS protocol.

;


Specification:

Frequency: 868MHz / 915MHz

Dimension: 18*12*3.2mm

Weight: 3.2g

Numbers of Channel: 4 PWM / 16 SBUS (CH16 outputs RSSI)

Operating Voltage: DC 3.5V~10V

Operating Current: <[email protected]

Compatibility: R9M Lite/ R9M Lite Pro / R9M 2019 with ACCESS firmware


Features:

ACCESS protocol and supports OTA functions

900MHz/868MHz long-range with low latency

Enhanced and durable design

Support S.Port / F.Port (Configurable in OpenTX / FrOS menu)

With inverted S.Port outputs

Signal redundancy function

Detachable Ipex1 connector antenna


Package Included: (Optional Version)

1 x R9M Lite Module with mounted Super 8 antenna

1 x R9 MX Receiver with mounted Ipex4 T antenna
