FrSky Taranis X9D Plus 2019 2.4G 24CH ACCESS ACCST D16 Mode2 Transmitter with R9M 2019 900MHz Long Range Transmitter Module - 209.00 €

FrSky Taranis X9D Plus 2019 2.4G 24CH ACCESS ACCST D16 Mode2 Transmitter with R9M 2019 900MHz Long Range Transmitter Module
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


FrSky Taranis X9D Plus 2019 2.4G 24CH ACCESS ACCST D16 Mode2 Transmitter with R9M 2019 900MHz Long Range Transmitter Module

OVERVIEW:(Transmitter)
The FrSky Taranis X9D Plus 2019 is a re-designed version with additions like an additional momentary button placed on the top left shoulder making it ergonomically friendly for DLG pilots to activate launch mode, and features a program scroll wheel making it even easier to navigate the menus. The upgraded MCU is applied to a re-structured mainboard that further increase the compute capability and extend the storage resource of data, the upgrades not only in favor of the running of LUA script, and also optimize the overall performance like voice speech outputs.
The 2019 version uses the latest ACCESS communication protocol, it boasts 24 channels with a faster baud rate and lower latency with a high-speed module digital interface. Along with the new spectrum analysis function added to the OpenTX firmware, it is now possible to check the airwaves for RF noise with an accurate SWR indicator. This version will give you the further improved experience based on the classic Taranis remote control. Additionally tons of extra upcoming features that ACCESS brings will make this an ideal transmitter for any skill level.
The SE 2019 version is installed with the upgraded switches and M9 hall sensor gimbals, and features the addition of a PARA wireless trainer function which makes them compatible with the FrSky Free Link App and AirLink S.

Note:
The X, XM, RX, GX series receivers can be gradually upgarded to ACCESS protocol. It includes XM, RXSR, RX4R, RX6R, G-RX6, G-RX8, XM Plus, and R9 series. For more details about ACCESS, pls. visit: https://www.frsky-rc.com/frsky-advanced-communication-control-elevated-spread-spectrum-access-protocol-release/

OVERVIEW:(Module)
FrSky R9 and R9M radio control system is the first FrSky long range system which works in the frequency of 900MHz. The R9M module offers 4 switchable RF power outputs to so you can choose the appropriate power for different flight situations. Compared to another FrSky 2.4GHz long range receiver like the L9R, the R9 receiver has a longer operating range up to 10KM and above. Moreover, the R9 is also a redundancy receiver which can connect to another receiver to ensure the security of your aircraft.

Note:
If S.Port is disabled, communication related to S. Port between R9M 2019 and the transmitter will be cut off.

SPECIFICATIONS:(TransmitterManual)
Brand: FrSky
Item name: X9D Plus 2019 Transmitter
Dimension: 200*194*110mm (L*W*H)
Weight: 670g (without battery)
Operating system: OpenTX
Mode: Mode 2
Number of channels: 24 channels
Internal RF module: ISRM-S-X9
Operating voltage range: 6.5 - 8.4V
Operating current: [email protected]
Operating Temperature: -20℃ ~ 60℃ (-4℉ ~ 140℉ )
Backlit LCD resolution: 212*64
Smart Port, Micro SD card slot and DSC Port
Micro USB interface: supports 2S Li-battery balancing charge
Model memories: 60 models (expandable by Micro SD card)
Compatibility: ACCST D16 and ACCESS receivers
Color: Ash White/Sky Blue/Silver

FEATURES:
Classic Taranis form factor design
Program navigation button
High-speed module digital interface
Easy launch momentary button
Installed with ACCESS protocol
Supports spectrum analyzer function
Accurate SWR indicator
G9D potentiometer gimbal
Haptic vibration alerts and voice speech outputs
Supports wired training function

Specification:User Manual
Brand: FrSky
Item Name: R9M 2019 900MHz Transmitter Module

Vin Voltage Range: 6.5V-13V
External Power Supply: 6.5V~13V
Telemetry Interface: Smart Port
Upgrade Interface: Smart Port
Modulations: PXX or CPPM (auto-detected)
RF Operating Frequency: 915MHz
Compatibility : R9 Series Receivers

Feature :
-900MHz/868MHz Working Mode
-Long Range, Low Latency and High Precision RC System
-4 Optional RF Power (Non-EU Version)
-Telemetry Mode (25mW)/Non-telemetry Mode (200mW / 500mW) (EU Version)
-RF Power (Flex): 10mW/ 100mW/ 500mW/ 1W (telemetry supported for all levels)
-Smart Port Enabled and Support Telemetry Data Transmission


How to enable/disable the S.Port of R9M 2019(Non-EU) Module
-- For Taranis Series transmitters, if you want to turn on the S.Port of R9M 2019, turn off the Internal RF.
-- For Horus Series transmitters, turn on the transmitter. go to the RF SYSTEM, choose the External RF
and select R9M, then choose S.Port or not.

Comparisom List:
Taranis X9D Plus 2019 Taranis X9D Plus SE 2019
Operating System OpenTX OpenTX
Communication Protocol ACCST D16 /ACCESS ACCST D16 /ACCESS
High-speed Module Digital Interface
Accurate SWR indicator
Spectrum Analyzer Function
Program Navigation Button
Easily Launch Momentary Button
Haptic Vibration Alerts
Voice Speech Outputs
2S Li-Battery Charging System
G9D Potentiometer Gimbal
M9 Hall Sensor Gimbal
Upgraded Switches
Wired Training System
PARA wireless training function
-PAPA High-speed training system with a lower latency
-Compatible with FrSky Free Link App and AirLink S via mobile devices

Package Included:
1 x X9D Plus 2019 Transmitter
1 x R9M 2019 Transmitter Module
