Brand name: Full Speed
Product name: Baby 16 x 16 Mounting Hole 2S Flight Tower
16x16 mounting hole F3 brushless flight controller :
FC product size: 20 x 20 x 5mm
Mounting hole : 16 x 16cm
Mounting hole diameter: 2mm
FC weight : 2g
BEC: 5V / 1A
Support TCP of receiver: DSM / PPM / SBUS
CPU: F3
Working voltage : 2S LiPo battery(7.4V)
Sensor : MPU6000
Built in Betaflight OSD
Firmware : F3 BetaFlight 3.1
Product feature:
- Support LED program
-Support Dshot 600 ESC TCP
-Support low voltage alarm
-Integrated OSD functions
-Support alarm function of buzzer
-Support SBUS / PPM / DSMX popular receiver
-Supper teeny 2S Flight controller
16 x 16 Mounting Hole 2S Brushless ESC:
ESC size : 20 x 22 x 5mm
Mounting hole: 16 x 16
Mounting hole diameter: 2mm
ESC weight: 2g
Firmware: BLHeli_S 16.6
LiPo Battery: 2S
Continuous current: 6A
Peak current: 7A(10 second)
Product feature:
-Four-in-one integration is easy to install
Package size: 6 x 8 x 2cm
Package weight: 4.0g
Package Content:
8 x M2 x 5 + 5 Nylon Column
4 x M2 Nylon Nut
1 x 6pin Flexible Flat Cable
1 x Flight Controller
1 x ESC
Product name: Baby 16 x 16 Mounting Hole 2S Flight Tower
16x16 mounting hole F3 brushless flight controller :
FC product size: 20 x 20 x 5mm
Mounting hole : 16 x 16cm
Mounting hole diameter: 2mm
FC weight : 2g
BEC: 5V / 1A
Support TCP of receiver: DSM / PPM / SBUS
CPU: F3
Working voltage : 2S LiPo battery(7.4V)
Sensor : MPU6000
Built in Betaflight OSD
Firmware : F3 BetaFlight 3.1
Product feature:
- Support LED program
-Support Dshot 600 ESC TCP
-Support low voltage alarm
-Integrated OSD functions
-Support alarm function of buzzer
-Support SBUS / PPM / DSMX popular receiver
-Supper teeny 2S Flight controller
16 x 16 Mounting Hole 2S Brushless ESC:
ESC size : 20 x 22 x 5mm
Mounting hole: 16 x 16
Mounting hole diameter: 2mm
ESC weight: 2g
Firmware: BLHeli_S 16.6
LiPo Battery: 2S
Continuous current: 6A
Peak current: 7A(10 second)
Product feature:
-Four-in-one integration is easy to install
Package size: 6 x 8 x 2cm
Package weight: 4.0g
Package Content:
8 x M2 x 5 + 5 Nylon Column
4 x M2 Nylon Nut
1 x 6pin Flexible Flat Cable
1 x Flight Controller
1 x ESC
Specification
General |
Type: ESC,Flight Controller |
|---|---|
Dimension and Weight |
Package weight: 0.0100 kg
Package size (L x W x H): 6.00 x 8.00 x 2.00 cm / 2.36 x 3.15 x 0.79 inches |
Package Contents |
Package Contents: 8 x M2 x 5 + 5 Nylon Column 4 x M2 Nylon Nut 1 x 6pin Flexible Flat Cable 1 x Flight Controller 1 x ESC |
