GEELANG DJI Titan 120x HD 120mm 2.5 Inch 3-4S Whoop FPV Racing Drone BNF Caddx Vista FPV Camera
Specification:
Brand name: GEELANG
Item name: Titan DJI 120x HD Whoop Drone
Wheelbaseï¼120mm
Sizeï¼144mm *164mm * 46mm
Join the protection circle Sizeï¼152mm *172mm * 46mm
Weightï¼ 97.25g ï¼without batteryï¼
Weightï¼116gï¼without battery Join the protection circleï¼
Flight Controller:
Flight controllerï¼GEELANG FC GHF411AIO Version:MATEKF411
MCU:STM32F411CEU6 (100MHZ, 512K FLASH)
Sensor: MPU-6000(SPI connection)
Board size:33 * 33MM
Power supply: 2-4S battery input (DC 7-17V)
Built-in 20A(each) BL he li S 4in1 ESC Dshot600 ready
Built-in Beta flight OSD(SPI Control)
Built-in Current meter Max 70A
Current meter scale set to 480
Built-in 5V 2A BEC
Built-in voltage detection
Built-in current sensor
Onboard 4in1 ESC MCU upgraded to EFM8BB21
Power supply: 2-4S LiPo/LiPo HV (7v/17v)
Current: 20A continuous peak 25A(5 seconds)
Support BL Heli Suite programmable
Factory firmware: G_H_30_REV16_7.HEX
Default protocol: DSHOT600
Motor
Motor Modeï¼GL1204 KV4500
No.of Cells(Lipo)ï¼3S-4S
Stator specificationsï¼D12 * H2 0.2mm
Configu-ration:9N12P
Stator Diamter:12mm
Stator Length:4mm
Shaft Diameter:Φ1.5mm .
Motor Dimension(Dia.*Len):Φ16.0mm*15.8mm
Magent specifications: N52H
Shift specifications: 2mm High strength steel
LED
RGB LED dual lights, adjustable flight control bf software support
Receiver
Frsky Mini XM+ EU version SPI receiver
Frsky D16 switchable
No ground interference ( Transmitter and receiver 1 m from the ground): 500m
TBS Crossfire version CRSF Protocol , Official TBS transmitter compatible
No ground interference ( Transmitter and receiver 1 m from the ground): 500m
Frskyï¼ac900ï¼SPI receiver D16switchable
compatible futaba s-fhss switchable
No ground interference ( Transmitter and receiver 1 m from the ground): 300m
PNP NO RXï¼No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc
VTX
Caddxvistaï¼Dimensions
Module: 30.45 x 29 x 13mm
Camera: 27.4 x 21.1 x 20.1mm
Weight: 29g (inc. camera); Module: 19g
Antenna Connector: u.FL
Operating Frequency: 5.725-5.85GHz
Transmitter Power (EIRP)
FCC/SRRC/MIC: <20dBm
CE: <14dBm
I/O Interface: USB-C, IPEX, 3-in-1 Port
Latency: Low Latency Mode (720p 120fps): 21-28ms
High-Quality Mode (720p 60fps): 30-40ms
Max Transmission Distance: FCC/SRRC: 4km; CE: 0.7km
Input Power: 7.4-26.4v
Package Included:
1 x Titan DJI 120x HD Whoop Drone
1 x TPU 360 Camera Mount
