Hobbywing Platinum HV 130A OPTO V4 Brushless ESC For RC Model
Description:
1. Excellent Motor Speed Governing
â High-performance 32-bit processor with a running frequency of 72MHz combined with advanced algorithm optimizes the speed governing.
â Together with the adjustable governor parameters guarantee every pilot a precise control experience.
2.A separate program port for connecting programmer on this ESC allows user to
â Program ESC,
â Check flight data include minimum voltage, maximum temperature, standardized RPM and speed curve
(in Heli Governing Store mode) of the flight parameters recorded by the ESC,
âUpgrade ESC firmware with a mutifunction LCD program box or a WiFi Module & our Apple/Android phone App.
3.DEO Technology
The DEO (Driving Efficiency Optimization or so-called “Active Freewheeling”)
technology implemented in the ESC has multiple advantages.
â Rapider response to throttle change.
â Higher driving efficiency, longer flight time.
â Lower ESC temperature and a more reliable operation.
Specifications:
Product Name: Platinum HV 130A OPTO V4
Type: Brushless, High Voltage
Cont./Peak Current: 130A/160A
Input: 6-14S LiPo
BEC Output: No
Input Wires: Red-12AWG-150mm*1/Black-12AWG-150mm*1
Output Wires: Black-12AWG-100mm*3
Input Connectors: No
Output Connecotors: No
(Note: All the wire length above is the original length not the length you see from the outside.)
Transmitter: Not Supported
LED Program Card: Not Supported
LED Program Box: Not Supported
LCD Program Box: Supported
WiFi Module: Supported
Program Port: Separate Program Port
Firmware Upgrade: Supported
Size: 101.0x45.5x27.0mm
Weight: 154g
Applications:550-600 Class Heli (Main Blade: 550-690mm)
.90-.140 Class Fixed-wing Airplane, 2m FAIF3A & 3D
EDF (with Diameterâ¦105mm)
Manual:
Package Included:
1x Hobbywing Platinum HV 130A OPTO V4 ESC
Manual:
Package Included:
1x Hobbywing Platinum HV 130A OPTO V4 ESC
