Specification:
| HSKRC XL9 9 Inch Frame |
Wheelbase: 390MM Meterial: Carbon Fiber + Aluminum column Arm board: 4mm Center board: 2mm Camera install distance: 22mm Frame Space: 23mm (Support 2 board flytower) Flight Controller: F3/F4 30.5x30.5mm install hole Weight: 164g |
| Racerstar BR2312 960KV Motor |
Height: 32.8mm
Width: 28.2mm
Weight: about 52g
Shaft: 6mm
Shaft length: 7.9mm
KV (rpm/V): 960
Voltage: 7.4-14.8V
Battery: 2-4S lipo battery
|
| Matek Systems F405-CTR FC |
FC Specifications:
MCU: 168MHz STM32F405
IMU: MPU6000 accelerometer/gyro (SPI)
Baro: BMP280 (I2C)
OSD: BetaFlight OSD w/ AT7456E chip
Blackbox: MicroSD card slot (SD/SDHC)
VCP, UART1, UART2, UART3, UART4, UART5
Built in inverter for SBUS input (UART2-RX)
PPM/UART Shared: UART2-RX
SoftSerial on TX2, S5 or S6 optional
Camera control on S6 or DAC optional
Smartaudio & Tramp VTX protocol supported
WS2812 Led Strip : Yes
Beeper : Yes
RSSI: Yes
PDB Specifications:
Input: 6~30V (3~6S LiPo) w/TVS protection
PDB: 4x30A (Max.4x46A), 6 layers*2oz copper PCB
BEC: 5V 2A cont. (Max.3A)
LDO 3.3V: Max.300mA for Spektrum RX
Current Sensor 184A (Scale 179)
Battery Voltage Sensor: 1:10 (Scale 110)
|
| Racerstar SPROG X 35A ESC |
Con. Current: 35A
Peak Current(10s): 40A
Lipo: 2-6S
Programming: YES
Quantity: 4PCS
Weight: 4g
Size(PCB): 36x13.5mm
|
| Gemfan 9047 Propeller |
Material: carbon nylon
Size: 9 x 4.7''
Color: black
Weight: 12g/pair
|
Package Included:
1 x HSKRC XL9 Frame Kit
1 x Matek F405-CTR FC
4 x Racerstar SPROG X 35A BLheli_S 2-6S ESC
4 x Racerstar 2312 960KV 2-4S Motor
2 x Gemfan 9047 Propeller cw
2 x Gemfan 9047 Propeller ccw
