iFlight Alpha A65 65mm F4 1S AIO 5A ESC & 48CH 25/50mW VTX Tiny Whoop FPV Racing Drone BNF w/ Battery & Handbag Combo - 125.00 €

iFlight Alpha A65 65mm F4 1S AIO 5A ESC & 48CH 25/50mW VTX Tiny Whoop FPV Racing Drone BNF w/ Battery & Handbag Combo
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


Specification:

Brand Name: iFlight

Model: Alpha A65 ( Combo Version)

Item Name: 65mm 1S F4 AIO 5A ESC & 25mW 50mW VTX Tiny Whoop FPV Drone

Wheelbase: 65mm

Body Size: 46x46mm

Weight: 24.5g ( without Battery)

Flight Time: 3-4mins cruising ( take example as 1S 300mAh Lipo)


SucceX-1S 5A Whoop F4 Flight Controller AIO VTX Board

( Click here buy separate replace part)

Brand Name: iFlight

Model: SucceX-1S

Item Name: F4 1S Flight Controller AIO 5A 4in1 ESC & VTX

Input Voltage: 1S Lipo

FC Firmware: MatekF411RX

MCU: STM32F411

Gyroscope: MPU6000

Barometer: No

Blackbox: No

INA Pad: n uart2

BEC Output: 5V @ 1.2A

Size: 29x29mm

Mounting Pattern: 25.5x25.5mm, M3 (half-hole)
Connector:Micro-USB
Weight: 5.4g
Onboard 5A BL_S 4in1 Brushless ESC

Con. Current: 5A

Burst Current: 6A

BLHeli: BLHeli_S

Firmware: O-H-30 BLS 16.8

Current Sensor: Yes

Current Scale: 400

Input Voltage: 1S Lipo
Signal Support: Dshot,Oneshot,Multishot
ESC Telemetry: NO
Onboard 5.8G 48CH PIT/25/50mW VTX

Input Voltage: 5V

Channels: 48CH

Power: PIT/25/50mW

Connector: UFL/IPEX

XING Nano 0802 22000KV Brushless Motor

( Clickhere to buy replace separate Motor)

Model: XING Nano 0802

KV: 22000KV

Input Voltage: 1S Lipo

Configuration: 9N10P

Stator Diameter: 2mm

Shaft: 1mm

Dimension: 11.4x9.1mm

Weight: 2.2g (with 30mm wire plug)

HQProp 31mm 3-Blade Propeller

Ducted Propeller Size: 31mm

Quantity: 10 CW & 10 CCW

Color: Color May Vary

800TVL 150° Camera

Power: DC 5V

Size: 14x12.2x12mm

Net weight: 1.6g

1S HV 300mAh 40C Lipo Batteray

Quantity: 5 PCS

Minimum Capacity: 300mAh

Configuration: JST-PH2.0 /HV4.35V/3.8V/1.14WH

Discharge Rate: 40C

Max Burst Discharge Rate: 60C

Net Weight: 8.1g

Dimensions: 65*11*6mm

Charge Plug: JST-PH2.0

Portable Storage Bag Carring Case Handbag

(Clickhere to buy replace separate one)

External Size: 170x110x88mm

Weight: 173.8g

- Durable EVA, crushing resistant, anti-shock,

water resistant material provides adequate protection from bumps, scratches and splashes

- With Internal mesh pocket can store other accessories at your convenience

- Inner net with zipper inside allocation to store antennas & accessories.


Features:

- Only 24.5g (without battery)

- Butter smooth XING 0802 (more torque and efficiency with longer flight times)

- Ducts to protect the sensitive environment or yourself

- Pre-tuned with smooth cinematic settings

- With Lipo Battery & Handbag


Package Included:

1x Alpha 65 Prebuilt and tested Quadcopter

1x 800TVL 150° Camera

1x SucceX-1S Whoop F4 AIO Board w/VTX

1x Whip antenna

10x HQ 31mm Propeller CW

10x HQ 31mm Propeller CCW

4x XING Nano 0802 22000KV Brushless Motor

1x 65mm Replace Body Frame

2x Replace Canopy

5x Lipo Battery

1x Handbag
