Description:
IMAX B6 style charger is the new intelligent multifunction charger which can charge and discharge for Lion, LiPo, LiFe (A123), Pb, NiCd and NiMH batteries. It's all-powerful in a way.
Main Features:
Microprocessor controlled delta-peak sensitivity
Individual cell balancing Li-ion, LiPo and LiFe capable Ni-Cd and NiMH capable
Large range of charge currents store function, allows safe storage current
Time limit function
Input voltage monitoring (Protects car batteries at the field)
Data storage (Store up to 5 packs in memory)
Battery break in and cycling
Support new generation A123 system (LiFe) battery
Specifications:
Operating voltage range: DC 11.0 - 18.0 Volt / AC to DC adaptor (DC 11.0-18.0V / 5A)
Circuit power: Max.charge power 50W / Max.discharge power 5W
Charge current range: 1.0 - 5.0A
Discharge current range: 0.1 - 1.0A
Current drain for balancing Li-po: 300mAH / cell
LiIon / LiPo / LiFe cells : 1-6
NiCd / NiMH cells : 1-15
Pb battery voltage: 2 - 20V
Main Features:
Microprocessor controlled delta-peak sensitivity
Individual cell balancing Li-ion, LiPo and LiFe capable Ni-Cd and NiMH capable
Large range of charge currents store function, allows safe storage current
Time limit function
Input voltage monitoring (Protects car batteries at the field)
Data storage (Store up to 5 packs in memory)
Battery break in and cycling
Support new generation A123 system (LiFe) battery
Specifications:
Operating voltage range: DC 11.0 - 18.0 Volt / AC to DC adaptor (DC 11.0-18.0V / 5A)
Circuit power: Max.charge power 50W / Max.discharge power 5W
Charge current range: 1.0 - 5.0A
Discharge current range: 0.1 - 1.0A
Current drain for balancing Li-po: 300mAH / cell
LiIon / LiPo / LiFe cells : 1-6
NiCd / NiMH cells : 1-15
Pb battery voltage: 2 - 20V
Specifications
Specifications |
Type: Chargers and Cables |
|---|---|
Dimension and Weight |
Package Weight: 0.845KG
Package Size (L x W x H): 21.000 x 17.000 x 6.000 cm /8.25 x6.68 x2.36 inches |
Package Contents |
Package Contents: 1 x Imax B6 LiPo Battery Balance Charger, 3 x Set of Wire, 1 x EU AC Power Adapter Cord, 1 x English Manual |
