Highlights
- 600mW (28dBm, +/- 1dB) of clean output power
- Frequencies: 5740, 5760, 5780, 5800, 5820, 5840, 5860MHz
- Not affected by 2.4GHz R/C radios
- On-board quiet switching regulator, powers 5v cameras (including HD versions)
Specification
| General | |
|---|---|
| Type | Transmitter |
| Connector | SMA ,with supplied 5.8GHz antenna. |
| Input Voltage Range | 7~25v |
| Camera Power Supply | 300mA / 5v |
| Video Input | 1Vpp, 75 Ohms |
| Size/Weight | Size: 50 x 23mm Weight: 18 grams |
| Compatible | QAV250 |
| Package Contents | |
| 1 x Transmitter | |
| 1 x Antenna (SMA connector) | |
| 1 x DC Power Cable | |
