Jumper X68S Part 7g F3 Dshot Flight Control AIO 32CH 25mW FPV Transmitter Built-in Infrared Timer
Specification:
item Name: F3 FC AIO 32CH 25mW FPV Transmitter Buit-in Infrared Timer
F3 Flight COntrol Board
Mian Chip: STM32F303
MPU6000
Input Voltage: Only 1S Lipo
BEC: NO
Transmitter: 5.8G 32CH 25mW FPV Transmitter
Weight: 7g
Features:
1. M1,M2,M3,M4 - U,V, W
These board connections are for the ESC (electronic speed controllers). As shown there are 3 holes per section which will match with your 3 motor wires.
The board comes packed with D-SHOT300 ESC x 4 to control your motors.
2. S.Bus or PPM
These ports demonstrate the 3 ports for your receiver negative (-), positive (+) and Signal. By connecting a receiver to these ports you will be able to easily bind to your transmitter.
3. Infrared Timer
Our system uses infrared diodes to allow easy lap tracking system. This system will pair with your USB dongle which is provided in the kit.
4. Battery Lead
Our board supports 1 cell batteries only (1s). Please ensure to double check your batteries details carefully before plugging in or it will cause damage to the electronics
5. USB
Our board comes with a special adapter to allow you to plug right into your computer. By using this port you will be able to edit/flash the board with the software of your choice (ex betaflight, cleanflight)
6.Video In
This port allows you to directly connect your micro camera for FPV experience.
Package Included:
1x F3 Flight Control AIO 32CH 25mW Transmitter
