| Item | Specification | |
| Eachine Wizard X220S |
Wheelbase: 220mm Frame arm: 4mm carbon fiber Weigh: 356g (without battery and camera mount) Take off weigh: 561g Package weigh: 1728g
3K carbon fiber frame kit, 4mm thickness and 15mm width frame arms, the width is 10mm less than Eachine Wizard X220.
Frame kit with camera angle scale and 30° camera mount for Runcam 3 for G opro session.
Anti-vibration sponges to protect the racer frome crashing.
|
|
| Eachine MN2206 2300KV motor |
KV: 2300 Max thrust: 1100G Length: 35MM NO.OF cell: 3-5S Diameter: 28MM Framework: 12N14P Shaft: 5mm Propeller: 5 inch Weight: 28g |
|
| Eachine 30A BLHELI_S 4 in 1 ESC |
Con. current: 30A Pe ak current (10S): 35A Input voltage: 2-5S BEC: 5V output Programming: YES Firmware: blheli_s Weight: 28g Size: 36*36MM |
|
| Eachine 1179 800TVL CCD camera |
Color: purple
Sensor: CCD
Resolution(horizontal center): 800TVL
Shell size: 25mm*25mm
Weight: 11g
Resolution: PAL: 1980H×1080 (2MP)
Format: PAL
Video output: 1.0Vp-p/75Ω
Automatic gain control: 0.25/0.50/0.75/1.00 adjustable, up to 55dB.
AWB: ON/OFF
Exposure mode: electron exposure
Electronic shutter: 1/50(1/60) - 1/100000 S
Gamma correction: 0.45/1.0
Synchronization method: internal synchronization
Lens: standard 2.8mm lens
Working voltage: DC12V (Wide Voltage, measured that can be work in 5-13V)
Workig current: 70mA (low power consumption)
Workig temperature: -20â--60â
Humidity: 0%~98%
Strong backlighting effect |
|
|
5.8G 40CH 25MW 200mw 600MW
switchable transmitter
|
Video Format : NTSC/PAL Channel: 40CH Operating Temperature : -10~85â
Connector: RP-SMA Female
Antenna connector: RP-SMA Male
|
|
| Omnibus F4 V3 flight controller |
Size: 36x36mm
Mount holes: 30.5x30.5mm
STM32 F405 MCU, Runs Betaflight 3.0.1 firmware, could run faster loop time.
Using F4 MCU controls OSD over SPI bus in DMA mode.
OSD Configation has been included in Betaflight GUI.
SBUS/PPM input (Pinheaders)
6PWM output (1-4Pinheaders and Sh1.0 Plug, 5-6 as Pinheaders)
With barometer
SPI Sensor MPU6000
Included 128Mbit Flash, please always use BEC for the FC.
Supported by BETAFLIGHT and dRonin
|
|
| Flysky FS-i6X 2.4GHz 10CH remote control |
Channel: 6-10 (Default 6)
Model Type: Fixed-Wing/Gl ider/Helicopter
RF Ran ge: 2.408-2.475GHz
RF Power: < 20dBm
RF Channel: 135
Bandwidth: 500KHz
2.4GHz System: AFHDS 2A / AFDHS
Modulation Type: GFSK
Stick Resolution 4096
Low Voltage Warning: < 4.2V
DSC port: PS/2 Port PPM
Chargeable: No
Antenna Length: 26mm (Dual Antenna)
Weight: 392g
Power: 6V DC 1.5AA*4
Display: STNTransflective Display, LCD 128x64 Lattice, VA 73x39mm, LCD with white backlight
Size: 174x89x190mm
On-line Update: Yes
Color: Black
Certificate: CE0678, FCC ID: N4ZFLYSKYI6X
|
|
| Flysky FS-A8S receiver |
Channels: PPM 8CH Model type: Multi-rotor
Frequency ran ge: 2.408-2.475GHz
Band width: 500KHz
Band number: 135
RX Sensitivity: -92 dBm
2.4GHz system: AFHDS 2A
Modulation type: GFSK
DSC port: PPM Transfer method: FHSS Data output: 1.5mm*3 Pin PPM
Antenna length: 26mm (Not including brass contacts)
Input power supply: 4.0-8.4V
Display method: LED No ground interference ( Transmitting and receiving 1 m from the ground): >300m Working current: 40mA Each channel data: depend on the transmitter Channel delay: <15mS Size: 20*14*5.3mm
Weight: 1.2g
Certificate: CE0678, FCCID: N45ZA8S00
|
|
| 1500mAH 4S 14.8V 75C battery |
Capacity(mAh) : 1500
Cells (s): 4
Weight (g): 177
Length(mm): 80
Width(mm): 30
Height(mm): 33
Connector: XT60
|
|
| Eachine 5051 3-blade propeller |
Color: purple Quantity: 10 Pairs Mounting Hole: 5mm |
|
Eachine wizard X220S FPV drone english manual
Package included:
1 x Eachine Wizard X220S frame kit
1 x Flysky FS-i6X remote control
1 x Flysky FS-A8S receiver
2 x 2206 2300KV motor CW
2 x 2206 2300KV motor CCW
1 x Eachine 30A BLHELI_S 4 in 1 ESC
1 x Omnibus F4 V3 flight controller
1 x 800TVL camera
1 x 5.8G 40CH 25MW 200mw 600MW switchable VTX
10 x Eachine 5051 3-blade propeller purple CW
10 x Eachine 5051 3-blade propeller purple CCW
1 x 1500mAH 4S 14.8V 75C battery
1 x 30° Camera Mount(For Runcam3/for G opro session)
1 x 30° Camera Mount(For Runcam3/for G opro session)
1 x Charger
1 x Pagoda antenna
2 x Battery strap
2 x Wrench
(Package doesn't include Runcam 3, the Runcam 3 on the pictures for reference only.)
(Package doesn't include Runcam 3, the Runcam 3 on the pictures for reference only.)
