Specifications
RF Output (50 Ohm): 700mW/28.5dBm +/- 1dB
Video input (75 Ohm): 1Vpp typical
Audio input (10K Ohm): 1Vpp typical
Dimensions (LxWxH: 57x23x12mm
Weight (Grams): 22 grams
Supply Voltage: 6-Â25V DC (2S-Â6S LiPo)
Power Consumption: 3 Watt
Power output: 5V, 1.5A max.
RF output: SMA female
Batteryinput: 2-pin Molex SL, 2.54mm
Audio/video input: 5-pin Molex SL, 2.54mm
Frequencies: 2396, 2410, 2430MHz (USA version)
Package contents
1pcs - ImmersionRC 700mW 2.4GHz audio/video transmitter.
1pcs - Linear polarized SMA male articulating, straight 2.4GHz antenna.
1pcs - Cable, featuring a Molex SL 2-pin female plug toJST2-pin male header.
1pcs - Cable, featuring a Molex SL 5-pin female plug to bare wire ends.
