Specification:
Model: Orion3
item Name: 167mm Wheelbase 3 Inch Racing Duct Frame Kit
Wheelbase: 167mm
Upper Plate Thickness: 1.5mm
Bottom Plate Thickness: 2mm
Inner Standoff Height: 25mm
Duct Height: 33mm
Net Weight: 180g ( only frame)
Frame Dimension: 237x215mm
Recommend Parts:
Flight Controller: 20x20mm /30.5x30.5mm F4/F7 Flight Controller
Brushless ESC: 20x20mm /30.5x30.5mm 30A 4in1 ESC
Brushless Motor: 1408 3800KV / 1507 3800KV Motor
Propeller: 3 Inch Propeller
Lipo Battery: 4S 1300mAh / 1500mAh Lipo Battery
The fllowing parts are compatible: ( NOT Included)
FC & ESC Stack: 20x20mm Flywoo GOKU F7 FC & 40A BL_32 2-6S ESC Stack
30.5x30.5mm iFlight SucceX-E F4 FC & 45A BL_S 2-6S ESC Stack
Brushless Motor: T-Motor F1507 1507 3800KV 3-4S Brushless Motor
iFlight XING 1408 4100KV 2-4S Brushless Motor
Propeller: 2 Pairs Gemfan Flash 3052 PC 3-blade Propeller 5mm Mounting Hole
2 Pairs Dalprop Cyclone T3056C 3056 3-blade Propeller PC ABS M5 Hole
Lipo Battery: AHTECH Infinity 4S 14.8V 1300mAh 85C Graphene LiPo Battery XT60
Package Included:
1x Upper Plate
1x Bottom Plate
4x Duct 2x EVA Protective Guard ( 2in1)
1x 3D Printed TPU Antenna Mount
1x 3D Printed Camera Mount for Hero 3/4
1x bag of Screws
