OverSky Scisky VTX-OSD 5.8G 40CH 25mW FPV Transmitter with OSD Plug and Play
Description :
Weight : 22g
Size : 22mm*25mm
Frequency checking and setting up on analog video transmitter (the operation way will be changed according to feedback from customers)
6 LED lights on the board indicates the working frequency of the video transmitter in binary calculation way, LED 1, LED 2, LED 3 represent 5 groups of frequency, LED A, LED B and LED C show 8 frequencies.
Pull the throttle to lowest, press the button slightly, you can check the current working frequency of the VTX (LED lights flash twice); Push the throttle to mid range, double press the button and then enters frequency set up mode; The LED light group shows the current working frequency when the VTX enters frequency set up mode, push or pull Elevator stick up and down, you can change the frequency groups (5 groups), pull Aileron stick right or left, you can change frequency points (8 frequency points in total); After finishing frequency set up, pull or push the throttle stick to highest or lowest position, frequency set up mode quits and the frequency changes to the set up frequency which is save on VTX, LED group lights flashes twice indicates the finished operation.
This VTX&OSD video transmitter is plug and play on Scisky 32 F1 or F3 flight control board.
LED1
LED2
LED3
LEDA LEDB LEDC
000
001
010
011
100
101
110
111
0
0
0
5740M
5760M
5780M
5800M
5820M
5840M
5860M
5880M
0
0
1
5865M
5845M
5825M
5805M
5785M
5765M
5745M
5725M
0
1
0
5733M
5762M
5771M
5790M
5809M
5828M
5847M
5866M
0
1
1
5705M
5685M
5665M
5645M
5885M
5905M
5925M
5945M
1
0
0
5658M
5695M
5732M
5769M
5806M
5843M
2880M
5917M
Package Included :
1 x 5.8G VTX&OSD
