Features:
Carbon Fiber Mini 250 FPV Quadcopter Frame Specifications:
Material: Carbon Fiber and Fiber Glass mix
Size: 220mm diagonally, 175mm wide, 130mm long motor-to-motor;
Maximum Propeller: 5 inch
Motor Mount: M2 12mm - 16mm
Flight Controller Mount: 30.5mm x 30.5mm
Board Camera Mount: 32mm x 32mm
MT1806 2280kv Brushless Motor Specification:
KV: 2280
Max Trust: 460g
No. of Cell: 2-3S
Framework: 12N14P
Propeller: 5 inch - 6 inch
Length: 26.7mm
Shaft: 2mm
Diameter: 23mm
Weight: 18g
12A Simonk ESC Specifications:
Max Continuous Load: 11 amps
Burst Current: 16A / 10sec
BEC: 5v / 1 amp max
Lipo Cells: 2 to 3 cells
Cables are fitted with female 2mm bullet connectors
Weight: 10g
Dimensions: 24mm L x 18mm W x 7mm H ( 29mm in length including capacitor )
15cm signal wire / 5v power
5cm motor wires ( including 2mm bullet connector )
Carbon Fiber Mini 250 FPV Quadcopter Frame Specifications:
Material: Carbon Fiber and Fiber Glass mix
Size: 220mm diagonally, 175mm wide, 130mm long motor-to-motor;
Maximum Propeller: 5 inch
Motor Mount: M2 12mm - 16mm
Flight Controller Mount: 30.5mm x 30.5mm
Board Camera Mount: 32mm x 32mm
MT1806 2280kv Brushless Motor Specification:
KV: 2280
Max Trust: 460g
No. of Cell: 2-3S
Framework: 12N14P
Propeller: 5 inch - 6 inch
Length: 26.7mm
Shaft: 2mm
Diameter: 23mm
Weight: 18g
12A Simonk ESC Specifications:
Max Continuous Load: 11 amps
Burst Current: 16A / 10sec
BEC: 5v / 1 amp max
Lipo Cells: 2 to 3 cells
Cables are fitted with female 2mm bullet connectors
Weight: 10g
Dimensions: 24mm L x 18mm W x 7mm H ( 29mm in length including capacitor )
15cm signal wire / 5v power
5cm motor wires ( including 2mm bullet connector )
Specification
General |
Type: Frame Kit |
|---|---|
Dimension and Weight |
Product weight: 0.320 kg
Package weight: 0.615 kg Product size (L x W x H): 22.00 x 17.50 x 13.00 cm / 8.66 x 6.89 x 5.12 inches Package size (L x W x H): 30.00 x 20.00 x 8.00 cm / 11.81 x 7.87 x 3.15 inches |
Package Contents |
Package Contents: 1 x 250 Quadcopter Frame, 1 x ESC Connection Board, 4 x MT1806 2280KV Brushless Motor, 4 x 12A Simonk ESC, 4 x 5030 Propeller, 1 x CC3D Flight Controller, 4 x Propeller Ring, 2 x Connecting Cable Set, 1 x Accessory Set |
