Description:
Brand: Racerstar
Product: DS6225MG Digital Servo
Operating Voltage: 4.8V-6.0V
Operating Speed (4.8V): 0.25 sec/60°
Operating Speed (6.0V): 0.21 sec/60°
Stall Torque (4.8V): 19.9 kg.cm
Stall Torque (6.0V): 25.3 kg.cm
Dead Band: 4μs
Working Frequence: 1520μs / 300hz
Max Angle: 300°
Pulse width: 800-2200μs=180°
Pulse width: 500-2500μs=320°
Gear: Metal Gear
Motor Type: DC Motor
Bearing: 2BB
Connector Wire Length: JR 260mm
Weight: About 62g
Dimension: 40.5X20.2X40mm
Application: For RC Robot
Package Included:
1 * Racerstar DS6225MG Digital Servo
