Racerstar Racing Edition BR1103 10000KV Motor + RS6Ax4 6A Blheli_S BB2 ESC + 10 Pairs Racerstar 2035 Propeller
Description:
Racerstar BR1103 10000KV motor:
Item No: BR1103 10000KV Brushless Motor
Height: 15.6mm
Width: 13.6mm
Weight: about 3.3g
Shaft: φ1.5mm
KV (rpm/V): 10000
Voltage: 3.7-7.4V
Battery: 1-2S lipo battery
Prop: 3 inch, 2 inch, 65mm
Racerstar RS6Ax4 Blheli_S BB2 ESC:
Item Name: 6A Blheli_S BB2 4 in 1 Brushless ESC
Model: MIni RS6Ax4
Lipo Battery: 1-2S
Con. Current: 6A
Peak Current: 10A (10S)
BEC: 5V @0.5A
Programming: YES
Size(PCB): 27x27mm
Weight: 4.5g (Not including the wire and screws)
M3 Installing Hole Distance: 20x20mm
-BB2, 48MHZ Chip
-Blheli_S Firmware,
-4 in 1 ESC, Super small size (27*27mm) and light weight, easy to install and use
-With 5V 0.5A BEC
-Support 1-2S Lipo Battery
-Support Oneshot42, Oneshot125, Multishot and 16.5 Dshot600
-All codes use damped light mode.Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling.
Package included:
4 x BR1103 10000KV motor
1 x RS6Ax4 Blheli_S BB2 ESC
Prop: 3 inch, 2 inch, 65mm
Racerstar RS6Ax4 Blheli_S BB2 ESC:
Item Name: 6A Blheli_S BB2 4 in 1 Brushless ESC
Model: MIni RS6Ax4
Lipo Battery: 1-2S
Con. Current: 6A
Peak Current: 10A (10S)
BEC: 5V @0.5A
Programming: YES
Size(PCB): 27x27mm
Weight: 4.5g (Not including the wire and screws)
M3 Installing Hole Distance: 20x20mm
-BB2, 48MHZ Chip
-Blheli_S Firmware,
-4 in 1 ESC, Super small size (27*27mm) and light weight, easy to install and use
-With 5V 0.5A BEC
-Support 1-2S Lipo Battery
-Support Oneshot42, Oneshot125, Multishot and 16.5 Dshot600
-All codes use damped light mode.Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling.
Racerstar 2035 50mm ABS Propeller:
Item name: 2035 4 Blade ABS Propeller
Length: 2 inch, about 50mm
Color: green, light blue, yellow, black, red
Quantity: 10 pairs (the same color)
Mounting hole: 1.5mm
Weight: 0.7g per propeller
Light, strong and well balanced for micro brushless FPV drones
Applicable for 1102, 1103, 1104, 11xx motors
Package included:
4 x BR1103 10000KV motor
1 x RS6Ax4 Blheli_S BB2 ESC
10 x 2035 propeller CW
10 x 2035 propeller CCW
40 x M2*7 screw
