Specification:
Brand Name: RCInpower
Model: Smoox 1404 Plus
Item Name: 1404 2750KV 4-6S / 3850KV 3-4S / 5000KV 2-3S Brushless Motor
KV: 2750KV / 3850KV / 5000KV ( Optional)
Color: Orange / Blue (Optional)
Quantity: 1 PC
Configuration: 9N12P
Shaft Dimeter: 1.5mm ï¼ 2mm Insideï¼
Stator Diameter: 12mm
Mounting Hole: 9x9, M2
Stator Length: 4mm
Dimension: 19.2x13.1mm
Weight: 9g ( Include 30mm wire)
| Optional KV | 2750KV | 3850KV | 5000KV |
| Input Voltage | 4-6S | 3-4S | 2-3S |
| Internal Resistance | 400mΩ | 250mΩ | 250mΩ |
| Idle Current (10V) | 0.35A | 0.57A | 0.35A |
| Peak Current (3S) | 6.8A | 9.5A | 6.8A |
| Max. Power ( 3S) | 150W | 150W | 150W |
Package Included:
1x RCInpower Smoox 1404 Plus Motor
1x bag of Screws
